PERFORMANCE |
Processor | Intel® Core™ i5-1235U, 10C (2P + 8E) / 12T, P-core 1.3 / 4.4GHz, E-core 0.9 / 3.3GHz, 12MB |
Graphics | Integrated Intel® Iris® Xe Graphics |
Chipset | Intel® SoC Platform |
Memory | 8GB Soldered DDR4-3200 + 8GB SO-DIMM DDR4-3200 |
Memory Slots | One memory soldered to systemboard, one DDR4 SO-DIMM slot, dual-channel capable |
Max Memory | Up to 40GB (8GB soldered + 32GB SO-DIMM) DDR4-3200 |
Storage | 256GB SSD M.2 2242 PCIe® 4.0x4 NVMe® |
Storage Support | Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 1TB • M.2 2280 SSD up to 1TB |
Storage Slot | Two M.2 2280 PCIe® 4.0 x4 slots |
Card Reader | 4-in-1 Card Reader |
Optical | None |
Audio Chip | High Definition (HD) Audio, Realtek® ALC3287 codec |
Speakers | Stereo speakers, 2W x2, Dolby® Audio™ |
Camera | FHD 1080p with Privacy Shutter |
Microphone | 2x, Array |
Battery | 3-cell (45Wh), integrated Supports Rapid Charge Pro (charge up to 50% in 30min) |
Battery Life | MobileMark® 2018: up to 6 hours Local video (1080p) playback@150nits: up to 8 hours *All battery life claims are approximate maximum and based on results using the MobileMark 2018, continuous 1080p video playback (with 150nits brightness and default volume level) or Google Power Load Test (PLT) battery-life benchmark tests. Actual battery life will vary and depends on many factors such as product configuration and usage, software use, wireless functionality, power management settings, and screen brightness. The maximum capacity of the battery will decrease with time and use. |
Power Adapter | 65W USB-C® (3-pin) |
DESIGN |
Display | 14" FHD (1920x1080) IPS 300nits Anti-glare, 45% NTSC |
Touchscreen | None |
Keyboard | Backlit, English |
Case Color | Mineral Grey |
Surface Treatment | Anodizing Sandblasting |
Case Material | Aluminium (Top), Aluminium (Bottom) |
Dimensions (WxDxH) | 323 x 218 x 17.9 mm (12.72 x 8.58 x 0.7 inches) |
Weight | Starting at 1.4 kg (3.09 lbs) |
SOFTWARE |
Operating System | Windows® 11 DG Windows 10 Pro 64, English |
Bundled Software | Office Trial |
CONNECTIVITY |
Ethernet | 100/1000M (RJ-45) |
WLAN + Bluetooth | Wi-Fi® 6E, 11ax 2x2 + BT5.1 |
Standard Ports | 1x Card reader 1x Ethernet (RJ-45) 1x HDMI® 2.1, up to 4K/60Hz 1x Headphone / microphone combo jack (3.5mm) 1x Thunderbolt™ 4 / USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4) 1x USB 3.2 Gen 1 1x USB 3.2 Gen 1 (Always On) 1x USB-C® 3.2 Gen 2 (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4) |
Docking | Various docking solutions supported via Thunderbolt™ or USB-C®. For more compatible docking solutions, please visit Docking for ThinkBook 14 G4 IAP |
Security Chip | Firmware TPM 2.0 Enabled |
Fingerprint Reader | Touch Style, Integrated in Power Button |
Physical Locks | Kensington® Nano Security Slot™, 2.5 x 6 mm |
Other Security | Camera privacy shutter |
MANAGEABILITY |
System Management | Non-vPro® |
ACCESSORIES |
Bundled Accessories | None |
CERTIFICATIONS |
Green Certifications | ENERGY STAR® 8.0 EPEAT™ Gold Registered ErP Lot 26 ErP Lot 6 RoHS compliant |
Other Certifications | TÜV Rheinland® Low Blue Light (Software Solution) |
Mil-Spec Test | MIL-STD-810H military test passed |
