SPECIFICATIONS:
GENERAL
Computer Connections
4
Port Selection
Hotkey, Pushbutton, Mouse, Remote Port Selector
CONNECTORS
Console Ports
2 x USB Type A Female
1 x HDMI Female (Black)
1 x 3.5mm Audio Jack Female (Green; 1 x front)
KVM (Computer) Ports
4 x USB2.0 Type B Female (Blue)
4 x HDMI Female (Black)
Power
1 x DC Jack
USB Hub
2 x USB2.0 Type A Female (White; 2 x front)
SWITCHES
Selected
4 x Pushbutton
LEDS
On Line /Selected
4 (Orange)
EMULATION
Keyboard / Mouse
USB
Video
Up to 4096 x 2160 @ 60Hz, 5120 x 1440 @ 60Hz
Scan Interval
1-99 Seconds (Default: 5 sec.)
Power Consumption
DC5V:1.73W:34BTU/h
Note:
● The measurement in Watts indicates the typical power consumption of the device with no external loading.
● The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
ENVIRONMENTAL
Operating Temperature
0-40°C
Storage Temperature
-20-60°C
Humidity
0-80% RH, Non-condensing
PHYSICAL PROPERTIES
Housing
Metal, Plastic
Weight
0.47 kg ( 1.04 lb )
Dimensions (L x W x H)
20.23 x 8.17 x 2.50 cm
(7.96 x 3.22 x 0.98 in.)
OTHERS
Cables Included
All HDMI & USB cables included
