SPECIFICATIONS:
Projection System |
| Projection System | DLP | DMD size | 0.65" | Marketing |
| Main Marketing Series | Business Projector | Product Features | 1.1X, TR 1.49~1.64, HDMIx2 | Display |
| Native Resolution | 1080P (1920x1080) | Native Aspect Ratio | 16:9 | Brightness (ANSI lumens) | 3800 | Contrast Ratio (FOFO) | 20000:1 | Selectable Aspect Ratio | 16:10,16:9,4:3,Auto,Real | Display Color | 30 Bits (1,07 billion colors) | Light Source | Lamp | Light Source Wattage | 203W | Light Source Life | a. Normal 6000 hrs,b. ECO 10000 hrs,c. SmartEco 10000 hrs,d. LampSave 15000 hrs | Optical |
| Throw Ratio | 1.49~1.64 | Zoom Ratio | 1.1x | Lens | F/# = 2.56 ~ 2.68, f = 22 ~ 24.1 mm | Projection Offset (Full-Height) | 100% | Keystone Adjustment | 1D, Vertical ± 40 degrees | ANSI Uniformity (Min.) | -55% | Clear Image Size | 60"~180" | Image Size | 30"~300" | Picture |
| Picture Modes | 3D,Bright,Infographic,Presentation,Spreadsheet,sRGB,User 1,User2 | Colour Wheel Segment (Lamp) | 6 segment (RGBYCW) | Colour Wheel Speed | 2X (60Hz),3X (50Hz) | Compatibility |
| Input Lag | 1 frame (16.67ms) 60Hz | Resolution Support | VGA(640 x 480) to WUXGA_RB(1920 x 1200) *RB=Reduced blanking | HDTV Compatibility | 1080i,1080p,480i,480p,576i,576p,720p | Video Compatibility | NTSC,PAL,SECAM | 3D Compatibility | Frame Packing,Frame Sequential,Side by Side,Top Bottom | I/O Interface |
| PC in (D-sub 15pin) | (x1) | Monitor out (D-sub 15pin) | (x1) | Composite Video in (RCA) | (x1) | S-Video in (Mini DIN 4pin) | (x1) | HDMI in | (x2),HDMI-1 (1.4a/HDCP1.4),HDMI-2 (1.4a/HDCP1.4) | USB Type A | (x1) | USB Type Mini B | (x1) | RS232 in (DB-9pin) | (x1) | Audio |
| Speaker | (x1),10W | Audio out (3.5mm Mini Jack) | 1 | Audio in (3.5mm Mini Jack) | 1 | Environment |
| Power Supply | AC 100 to 240 V, 50/60 Hz | Typical Power Consumption (110V) | 260W/110V | Acoustic Noise (Typ./Eco.)(dB) | 34/29 | Operating Temperature | 0~40℃ | Accessories |
| Carry Bag | Yes,5J.J3T09.001 (optiol) | Remote Control w/ Battery | RCX016 | Power Cord (by region) | x1 (1.8M) | VGA(D-sub 15pin) Cable | (Standard),1 (1.5m) | User Manual CD | 1 (24L) | 3D Glasses | (Optional),DGD5 | Quick Start Guide | 1 (21L) | Warranty Card (by region) | Yes | Universal Ceiling Mount | (Optional),Yes, CMG3 | OSD |
| OSD Language | 30L | Dimension & Weight |
| Dimensions (WxHxD) (mm) | 296 x120 x221 | Net Weight (kg) | 2.3 |
|
