Product condition:
OPENED BOX
This item is in excellent, new or like-new condition with no or minimal wear, Depending on the manufacturer or supplier, this item is either covered by original manufacturer’s warranty or three months standard warranty provided by PCByte. This item may be missing the original packaging or protective wrapping, or may be in the original packaging but not sealed, but we guarantee the item is well-packed with sufficient protection during order collection or delivery. This item may be missing original or minor accessories but we will provide necessary components to make sure the major element(s) is/are fully functional.
SPECIFICATIONS:
SYSTEM PARAMETERS
Processor
High-Performance Embedded SOC Processor
Operating System
Linux
CAMERA PARAMETERS
Image sensor
1/2.8” 2-Megapixel Progressive Scan CMOS Sensor
Lens
2.8 mm @ F1.6; 128° (Diagonal), 108° (Horizontal)
Lens Mount
M12
Night Vision
IR Distance:10m, IR-cut filter with auto-switching
VIDEO PARAMETERS
Video Compression
H.265
Max. Resolution
FHD 1920 x 1080
Frame Rate
15fps. Self-Adaptive during network transmission
DNR
3D DNR
WDR
DWDR
AUDIO PARAMETERS
Audio Input
Built-in omnidirectional microphone
Audio Output
Built-in loudspeaker
Audio Quality
Noise suppression
CAMERA EVENT
Sensor
PIR Motion Detection Sensor
Alarm
Customized Alert Area
Siren
105 dB built-in siren
CAMERA NETWORK PARAMETERS AND STORAGE
Wireless
Built-in 2.4G Wi-Fi
Network Configuration
AP Pairing
Minimum Network Requirement
1Mbp
Local Storage
Support MicroSD card up to 256 GB in Base Station
Cloud Storage
EZVIZ Cloud Storage
BASE STATION PARAMETERS
Camera pairing
Support up to 4 BC1 cameras
Buttons
1 SYNC button; 1 POWER button; 1 RESET button (hold 5 seconds to RESET)
Siren
125 dB built-in siren
Local Storage
MicroSD card slot on the base station (up to 256 GB)
Antenna
2.4G: 2 internal @ 3dB
Indicator
RGB 3 LED Indicator; 1 network Indicator
USB
Do not support
Network Interface
1 RJ-45 10/100Mbps Self-adaptive Ethernet WAN interface.
Wireless Interface
Support 2.4G connection. The actual available channels vary according to the sales area regulations. Theoretical maximum rate is 144M at 802.11b/g/n.
Power
12V/1A typical power consumption < 12watts; The adapter supports a wide voltage range from 100V~240V
GENERAL
Operating Conditions
-20°C to 45°C (-4°F to 113 °F), Humidity 95% or less (non-condensing)
Power Supply
12900mAh Rechargeable Lithium Battery or 5V DC
Power Consumption
Max. 5W
IP Grade
IP 66
Dimensions
Camera: 104.76 x 62.80 x 62.80 mm (4.12 x 2.47 x 2.47 inch)
Packaging Dimensions
186.00 x 103.00 x 103.00 mm (7.32 x 4.05 x 4.05 inch)
