SPECIFICATIONS:
Key specs
Motherboard Support:Mini-ITX, MicroATX, ATX
Enclosure Type:Compact Mid-Tower
Case Material:SGCC Steel, Clear Tempered Glass
Dimensions
Height:460mm / 18.11 inches
Width:210mm / 8.27 inches
Depth:428mm / 16.85 inches
Weight:6.8 kg / 15lbs
Compatibility & clearance
Max CPU Cooler Clearance:165mm
Max GPU Clearance:321 - 381mm
Front Fan & Radiator Clearance:60mm
Vertical GPU Clearance:50.8mm
Cable Management:19 - 23mm
Front I/O ports
USB 3.2 Gen 2 Type-A:1
USB 3.2 Gen 1 Type-C:1
Headset Audio Jack:1
Smart device
Fan Channels:3 (10W max per channel)
NZXT RGB Connector:2 (Support up to 40 LEDs)
Expansion slots
Standard:7
Vertical:2
Drive bays
2.5":2 + 1
3.5":2 + 1
Fan support
Front:2 x 120mm / 2 x 140mm
Top:1 x 120mm / 1 x 140mm
Rear:1 x 120mm
Filters:All air intakes
Radiator support
Front:280mm
Top:-
Rear:120mm
Fan specs
Model:Aer P 120mm (Case Version)
Speed:1,200 ± 200RPM
Airflow:50.42 CFM
Noise:28 dBA
Fan Connector:3-pin
Inside the box
H510i Case
2 x Aer F 120mm (Case Version)
Smart Device V2
Integrated LED Strips
Headset Audio Jack Splitter
Breakout Cable
Installation Accessories
Manual
