SPECIFICATIONS:
PICTURE/DISPLAY |
| LCD panel type | IPS technology | Backlight type | W-LED system | Panel Size | 23.8 inch / 60.5 cm | Display Screen Coating | Anti-Glare, 3H, Haze 25% | Effective viewing area | 527.04 (H) x 296.46 (V) | Aspect ratio | 16:9 | Maximum resolution | 1920 x 1080 @ 100 Hz* | Pixel Density | 93 PPI | Response time (typical) | 4 ms (GtG)* | Brightness | 250 cd/m² | Contrast ratio (typical) | 1000:1 | SmartContrast | 50,000,000:1 | Pixel pitch | 0.2745 x 0.2745 mm | Viewing angle | 178º (H) / 178º (V), @ C/R > 10 | Features | Flicker-free LowBlue Mode EasyRead sRGB Adaptive sync | Picture enhancement | SmartImage | Display colors | 16.7 M (8 bits) | Color gamut (typical) | NTSC 87%*, sRGB 99%* | Scanning Frequency | VGA/DVI: 30 - 115 kHz (H) / 48 - 60 Hz (V) ; HDMI/DP 30 - 115 kHz (H) / 48 - 100 Hz (V) | CONNECTIVITY |
| Sync Input | Separate Sync, Sync on Green | HDCP | HDCP 1.4 (HDMI / DisplayPort) | Signal Input | VGA (Analog) x 1, DVI-D x 1, HDMI 1.4 x 1, DisplayPort 1.2 x 1 | CONVENIENCE |
| User convenience | Power On/Off, Menu/OK, Brightness/UP, Input/Down, SmartImage/Back, Brightness, Input, Menu, SmartImage | Control software | SmartControl | OSD Language | Brazil Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Simplified Chinese, Swedish, Turkish, Traditional Chinese, Ukrainian | Other convenience | Kensington lock, VESA mount (100x100mm) | Plug & Play Compatibility | DDC/CI, Mac OS X, sRGB, Windows 11 / 10 / 8.1 / 8 | STAND |
| Tilt | -5/20 degree | POWER |
| On mode | 19.7 W (typ.) | Standby mode | 0.3 W (typ.) | Off mode | 0.3 W (typ.) | Power LED indicator | Operation - White, Standby mode- White (blinking) | Power supply | Built-in, 100-240VAC, 50-60Hz | DIMENSIONS |
| Product with stand (mm) | 540 x 418 x 220 mm | Product without stand (mm) | 540 x 322 x 57 mm | Packaging in mm (WxHxD) | 600 x 420 x 133 mm | WEIGHT |
| Product with stand (kg) | 2.92 kg | Product without stand (kg) | 2.60 kg | Product with packaging (kg) | 5.01 kg | OPERATING CONDITIONS |
| Temperature range (operation) | 0°C to 40°C °C | Temperature range (storage) | -20°C to 60°C °C | Relative humidity | 20%-80 % | Altitude: Operation | +12,000ft (3,658m), Nonoperation: +40,000ft (12,192m) | MTBF | 50,000 (Excluded backlight) hour(s) | SUSTAINABILITY |
| Environmental and energy | RoHS, Mercury Free | Recyclable packaging material | 100 % | COMPLIANCE AND STANDARDS |
| Regulatory Approvals | CE Mark, CEL, FCC Class B, ICES-003 | OTHERS |
| Notes | * The maximum resolution works for HDMI input only. * Response time value equal to SmartResponse * NTSC Area based on CIE1976 * sRGB Area based on CIE1931 |
|
