SPECIFICATIONS:
Hardware
Management Type
Web Managed
Number of Ports
12
10GbE SFP+
8
10GbE SFP+/RJ45 Combo Ports
4
Note: The 10GbE SFP+ ports are backward compatible with 1GbE SFP; the RJ45 (copper) combo port supports up to five speeds (10G/5G/2.5G/1G/100M).
Management Port
1 x 1GbE RJ45
Power Supply Description
Internal Power Supply Unit
Max. Power Consumption
70W
Input Power Type
AC
Input Voltage Range
100 ‒ 240VAC, 50/60Hz
MAC Address Table
32K
Total Non-Blocking Throughput
120Gbps
Switching Capacity
240Gbps
Management Interface
Web
Console
RS232
Energy Efficient Ethernet
(IEEE 802.3az complaint)
Fan
System: 4 x 4 cm (12V)
Supported Standards
IEEE 802.3 Ethernet IEEE 802.3u 100BASE-T IEEE 802.3ab 1000BASE-T IEEE 802.3bz 2.5G/5GBase-T IEEE 802.3an 10G BASE-T IEEE 802.3z 1000BASE-SX/LX IEEE 802.3ae 10G Fiber IEEE 802.3x Full-Duplex Flow Control IEEE 802.1Q VLAN Tagging IEEE 802.1w RSTP IEEE 802.3ad LACP IEEE 802.1AB LLDP IEEE 802.3az Energy Efficient Ethernet (IEEE 802.1p Class of Service)
LED Indicators
Per Port: Speed/Link/Activity Per System: Power/Status
Buttons
Reset button
Dimensions (HxWxD)
46.65 x 285 x 236.6 mm
Weight (Net)
2.16 kg
Operating Temperature
0°C to 40°C (32°F to 104°F)
Relative Humidity
5%–95% (non-condensing)
Certifications
FCC, CE, VCCI, BSMI, RCM, WEEE
Electromagnetic Compliance
CLASS A
Jumbo Frames
9K
Software
Standards Compliance
IEEE 802.3 Ethernet
IEEE 802.3u 100BASE-T
IEEE 802.3ab 1000BASE-T
IEEE 802.3bz 2.5G/5GBase-T
IEEE 802.3an 10G BASE-T
IEEE 802.3z 1000BASE-SX/LX
IEEE 802.3ae 10G Fiber
IEEE 802.3x Full-Duplex Flow Control
IEEE 802.1Q VLAN Tagging
IEEE 802.1w RSTP
IEEE 802.3ad LACP
IEEE 802.1AB LLDP
IEEE 802.3az Energy Efficient Ethernet
IEEE 802.1p Class of Service
Port Management-
Port status
Port statistics
Port configuration
Jumbo frame support
IEEE 802.3x flow control
Auto-negotiation of speed and duplex modes
QoS
Port-based QoS
IEEE 802.1p CoS
IPv4 DSCP-based QoS
IPv4 ToS-based QoS
VLAN
VLAN configuration
IEEE 802.1Q-based VLAN
Layer 2 Features
LACP
IGMP snooping v2 and v3
Security
Access Control Lists (ACL): ACL by IP address, ACL by MAC
Firmware management
Firmware Live Update
Firmware Manual Update
Other Features
Link Layer Discovery Protocol (LLDP): LLDP remote device
Interface: Web UI
SNTP, DNS, DHCP client entry
RSTP
IEEE802.1w Rapid Spanning Tree
