SPECIFICATIONS:
Model (safety certification)
SST-AX1000MCGD-C
Color
White (lead-free paint)
Max. DC Output
1000W
Power density
553.7W/L
Combined +3.3V & +5V
110W
Combined +12V
Input Voltage
90 ~ 264 Vrms
Input Frequency Range
47Hz ~ 63Hz
PFC
Active PFC（PF>0.9 at full load）
Efficiency
≥87% to <89% overall efficiency
MTBF
100,000 hours
Operating temperature
0°C ~ 40°C
Protection
Over power protection
Over current protection
Over voltage protection
Short circuit protection
Over Temperature protection
Connectors
1 x 24 / 20-Pin motherboard connector
2 x 8 / 4-Pin EPS / ATX 12V connector
1 x 12+4-Pin 12V-2x6 connector
4 x 8 / 6-Pin PCIe connector
8 x SATA connector
4 x 4-Pin Peripheral connector
Cooling System
Single 120mm FDB fan
Noise Level
18 dBA min.
Certification
Cybenetics Gold
Form factor
ATX (PS2)
Dimension
150mm (W) x 86mm (H) x 140mm (D)
5.91" (W) x 3.39" (H) x 5.51" (D)
Weight
2.7 kg
