Please Check Modem/Router Compatibility with your Service Providers Before Purchasing
SPECIFICATIONS:
Hardware Features | Standards | IEEE802.3, IEEE802.3u | Interface | 2 Ethernet ports per mesh node WAN and LAN on primary mesh node; Both act as LAN ports on additional mesh nodes | Antenna | 2*3dBi internal dual band antennas | Button | 1 reset button | Power | Input:100-240V, 50/60Hz, 0.3A OutputοΌDC 9V==1A | Dimensions | 90 x 90 x 90mm | Wireless Features | Wireless Standards | IEEE 802.11ac/a/n 5GHz IEEE 802.11b/g/n 2.4GHz | Wireless Frequency | 2.4G: 2400MHz-2483MHz 5G: 5150MHz-5250MHz or 5725MHz-5825MHz | Data Rate | 5GHz: Up to 867Mbps 2.4GHz: Up to 300Mbps | Frequency | Simultaneous dual band 2.4GHz & 5GHz | Basic Features | SSID Broadcast Beamforming | Wireless Security | Mixed WPA/WPA2-PSK(default) | Wireless Roaming | Comply with IEEE802.11v/r | Software Features | Internet Connection Type | PPPoE, Dynamic IP, Static IP, Bridge Mode | DHCP Server | DHCP Server DHCP Client List | Virtual Server | Port Forwarding UPnP | QoS | Support Smart QoS | Firewall | Forbid UDP flood attack Forbid TCP flood attack Forbid ICMP flood attack | DNS | Support manually setting DNS server | Firewall | Forbid UDP flood attack Forbid TCP flood attack Forbid ICMP flood attack | Others Setup Requirements | Parental Control Guest Network Firmware upgrade online Reset to factory settings A mobile device running Android 4.0+ or iOS 8+ | Others |
| Temperature | Operating Temperature: 0β ~ 40β Storage Temperature: -40β ~ 70β |
| Humidity | Operating Humidity:10% ~ 90% RH non-condensing Storage Humidity: 5% ~ 90%RH non-condensing |
| Certificates | FCC, CE, RoHS, EAC, IC |
| Package Contents(1-pack) | 1 identical mesh node 1 power adapter 1 quick install guide 1 ethernet cable |
|
|
