80 x 22 x 3.35mm / 3.15 x 0.86 x 0.13inch (with heat sink)
80 x 22 x 2.05mm / 3.15 x 0.86 x 0.08inch (without heat sink)
Weight
10.6g / 0.37oz (with heat sink)
6.5g / 0.23oz (without heat sink)
Interface
PCIe Gen4 x4
Sequential Read (Max)
Up to 7,000MB/s (PC/Laptop)*
Sequential Write (Max)
Up to 5,400MB/s*
Operating temperature
0°C - 70°C
Storage temperature
-40°C-85°C
Shock resistance
1,500G/0.5ms
MTBF
1,500,000 hours
Terabytes Written (TBW)
1,200TB**
Notes
* This product is compatible with the latest Intel and AMD platforms and must be used with a motherboard that supports PCIe 4.0 to achieve optimal performance. Actual performance may vary depending on the hardware and software configurations.
* This product is backward compatible with PCIe 3.0. If a third-generation PCIe motherboard is used, this product will be able to achieve sequential read/write speeds of 3400/3000MB per second.
* Test system configuration : M/B: MSI X570 Gaming Plus Max , CPU: AMD Ryzen 7 3700X 8-Core Processor 3.6GHz, RAM: ADATA 8G DDR4-2666MHz
** The value is the minimum amount of terabyte written that could be reached.
