SPECIFICATIONS:
Dimensions (L X W X H)
140 x 150 x 86mm
Cybenetics Rating
GOLD
80 Plus Rating
ATX Version
Intel ATX 12V v3.1
Protections
OVP / OPP / SCP / OCP / UVP / OTP / NLO / SIP
Certification
CB / CE / FCC / TUV / cTUVus / BSMI / CCC NOM / FCC IC / UKCA / TUV / TUV S-Mark / cTUVus
PFC
0.99
Input Voltage
100-240V
Input Current
10A
Input Frequency
47Hz-63Hz
DC Output Voltage
+5V | +3.3V | +12V | -12V | +5Vsb
Total Output
+5V/+3.3V :22A, +12V:62.5A, -12V:0.3A, +5Vsb:3A
Power Excursion
1762W (*up to 235% of the PSU's rated power for 100μs)
Operating Temperature
40°C
Fan Size
120mm FDB Fan
Fan Bearing
FDB (Fluid Dynamic Bearing)
Fan Speed
2400 RPM
MTBF
100K hours at full load
ATX 24 PIN Connector
1
EPS 8 PIN Connector
2
PCI-E 6+2 PIN Connector
3
MOLEX 4 PIN Connector
12V-2X6 (12+4) Connector (600W)
SATA Connector
6
Weight
Product + Cables: 1450g+1350gwith Package: 3.03kg
