Adata XPG SX8600 Pro 2TB PCIe Gen3 M.2 2280 NVMe SSD (ASX8600PRO-2T-CS)

Form Factor

M.2 2280

NAND Flash

3D NAND

Controller

SM2262EN

Dimensions (L x W x H)

80 x 22 x 4.38mm / 3.15   x 0.87 x 0.17inch (with heatsink)
  80 x 22 x 3.38mm / 3.15 x 0.87 x 0.13inch (without heatsink)

Weight

11g / 0.38oz (with   heatsink)
  8g / 0.28oz (without heatsink)

Interface

PCIe Gen3 x4

Sequential Read (Max)

Up to 3,500MB/s*

Sequential Write (Max)

Up to 3,000MB/s*

4KB Random Read IOPS(Max)

Up to 390K*

4KB Random Write IOPS(Max)

Up to 380K*

Operating temperature

0°C   - 70°C

Storage temperature

-40°C-85°C

Terabytes Written (TBW)(Max Capacity*)

1,280TB**

Shock resistance

1500G/0.5ms

MTBF

2,000,000 hours

Note

* Performance may vary   based on SSD capacity, host hardware and software, operating system, and   other system variables.

** The value is the   minimum amount of terabyte written that could be reached.

*** The SSD is based on   the TBW or Warranty period.

Visit   www.adata.com/us/support/xpg?tab=warranty&warranty=warrantyService for   more details.
