1 x DisplayPort Female 2 x USB Type A Female 1 x 3.5mm Audio Jack Female (Green) 1 x 3.5mm Audio Jack Female (Pink)
KVM (Computer) Ports
2 x DisplayPort Male 2 x USB Type A Male 2 x 3.5mm Audio Jack Male (Green) 2 x 3.5mm Audio Jack Male (Pink)
LEDS
KVM Port (On Line /Selected)
2 (White)
CABLE LENGTH
KVM
2 x 1.2 m
Remote Port Selector
1.8 m
EMULATION
Video
4096 x 2160 @ 30Hz
Power Consumption
DC5V:1.38W:28BTU/h
Note: The measurement in Watts indicates the typical power consumption of the device with no external loading. The measurement in BTU/h indicates the power consumption of the device when it is fully loaded.
ENVIRONMENTAL
Operating Temperature
0 - 50°C
Storage Temperature
-20 - 60°C
Humidity
0-80% RH, Non-condensing
PHYSICAL PROPERTIES
Housing
Plastic
Weight
0.35 kg ( 0.77 lb )
Dimensions (L x W x H)
8.34 x 8.42 x 3.04 cm (3.28 x 3.31 x 1.2 in.)
Note: For some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.
