Cooler Master MasterBox K501L Mid Tower ATX Case (MCB-K501L-KANN-S00)
MasterBox K501L Mid‑tower ATX case with left 4 mm tempered glass, 1×120 mm red LED front fan, 1×120 mm rear fan, up to 7 expansion slots, supports ATX/M‑ATX/ITX, 2×3.5″ & 2×2.5″ drives, USB 2.0 & 3.2 Gen1, cable routing 19‑27 mm.
Our team is ready to help! Please contact us if you have any questions about product specifications, stock availability, or compatibility.
Cooler Master MasterBox K501L ATX Case
MODEL NUMBER
MCB-K501L-KANN-S00
SERIES
Masterbox series
COLOR
BLACK
SIZE
MIDDLE TOWER
DIMENSION
499.5mm x 217mm x 468.5mm (incl. Protrusions), 428.7mm x 205mm x 458.5mm (excl. Protrusions)
NET WEIGHT
7 kg / 15.43 lbs.
SIDE PANEL
4mm Tempered Glass x1 (Left)
MATERIAL
Plastic, Acrylic
COOLING SYSTEM
Rear (exhaust) :
120 x 120 x 25 mm fan
(1000rpm, 19.5dBA)
EXPANSION SLOTS
7
MOTHERBOARDS
ATX, Micro ATX, Mini ITX
5.25" DRIVE BAYS
0
3.5" DRIVE BAYS
2
2.5" DRIVE BAYS
2
I/O PORT
1x USB 2.0, 1x USB 3.2 Gen 1 (formerly USB 3.0), 1x 3.5mm Audio Jack, 1x 3.5mm Mic Jack
PSU
Standard PS2 PSU (optional)
PRE INSTALLED FANS FRONT
1x 120mm Red LED
PRE-INSTALLED FANS - REAR
1x 120mm (Black)
FAN SUPPORT
FRONT
2x 140mm, 3x 120mm
TOP
2x 120/140mm
REAR
1x 120mm
RADIATOR SUPPORT
FRONT
120mm, 140mm, 240mm, 280mm, 360mm
TOP
120mm, 240mm
REAR
120mm
CLEARANCE
CLEARANCE - CPU COOLER
165mm
CLEARANCE - PSU
390mm (without radiator and HDD installed), 200mm (with radiator and HDD installed)
