SPECIFICATIONS:
TECHNICAL INFORMATION
Connectivity Technology
Wired
Number of Displays Supported
4
MANAGEMENT FEATURES
Host PC Management
Intel® AMT over Thunderbolt™ with select Intel® vPro® PCs
MAC address pass-through
PXE Boot
Dock Power Button Sync
Wake-On-LAN
WLAN to LAN switch
Kernel Direct Memory Access (DMA) protection
Dock Management Features
Remote firmware updates without a PC
Host-based firmware updates
Firmware update on disconnect
Port Disablement independent of PC
Device Supported
Notebook
VIDEO RESOLUTION
DP1.4 / DP2.1 with Display Stream Compression
Up to:
4 x 4K (3840x2160) @ 60Hz
3 x 4K (3840x2160) @ 60Hz
2 x 6K (6144 x 3456) @ 60Hz
1 x 8K (7680 x 4320) @ 60Hz
DP1.4 without Display Stream Compression
4 x QHD (2560x1440) @ 60Hz
3 x WQHD (3440 x 1440) @ 60Hz
2 x 4K (3840x2160) @ 60Hz
1 x 5K WUHD (5120 x 2160) @ 60Hz
NETWORK & COMMUNICATION
Ethernet Technology
RJ45 Ethernet port, 2.5GbE
INTERFACES/PORTS
Interfaces
Video interfaces
2 x DP1.4
1 x HDMI 2.1
1 x USB-C 3.2 Gen 2 Multi-function DisplayPort 1.4
2 x Thunderbolt 4
USB Ports (Data Only)
4 x USB-A 3.2 Gen 2 (10 Gbps)
1 x USB-C 3.2 Gen 2 (10 Gbps)
USB Ports (Power)
4 x USB-A 3.2 Gen 2 (4.5W each)
1 x USB-C 3.2 Gen 2 (15W)
1 x USB-C Multi-function DisplayPort (7.5W)
2 x Thunderbolt 4 (15W each)
All deliver power with or without PC
USB Power Delivery
130W (Dell systems)
96W (non-Dell systems)
SOFTWARE
Operating System Supported
Windows 10
Windows 11
Ubuntu
Red Hat Enterprise Linux
ChromeOS
macOS
POWER DESCRIPTION
Maximum Power Supply Wattage
180W
PHYSICAL CHARACTERISTICS
Height
205mm
Width
90mm
Depth
35.25mm
Weight (Approximate)
579g
MISCELLANEOUS
Package Contents
Docking Station
Power Adapter and Power Cord
Documentation (Quick Start Guide, Safety, Environmental, and Regulatory Information)
Kensington Security Slot
Yes
