Rating (VA/W) | 1150VA / 920W |
Format | Tower |
Technology | Line-Interactive High Frequency (Pure Sinewave, Booster + Fader) |
Input nominal voltage | 200V-240V |
Input voltage range without using batteries | 160V-294V (adjustable to 150V-294V) |
Input frequency range without using batteries | 47 to 70 Hz (50 Hz system), 56.5 to 70 Hz (60 Hz system), 40 Hz in low-sensitivity mode |
Output voltage | 230V (+6 / -10 %) (Adjustable to 200V / 208V / 220V / 230V / 240V), 50 / 60 Hz + / - 0.1 Hz (autosensing) |
Input | IEC C14 (10A) |
Output | 2 x AU 10A, 3 x IEC C13 (10A) |
Switched outlets groups | 2 outlet groups |
Typical backup times * | 200W: 34 300W: 19 400W: 13 600W: 7.5 800W: 4 * Backup times are approximate and may vary with equipment, configuration, battery age, temperature, etc. |
Battery management | Eaton ABM + or constant voltage charging method (user selectable), enhanced battery life time prediction based on usage conditions, battery exchange wizard, automatic battery test, deep discharge protection |
Communication ports | 1 USB port + 1 serial RS232 port and relay contacts (USB and RS232 ports cannot be used simultaneously), 1 mini terminal block for Remote ON/OFF and Remote Power OFF |
Communication slot | 1 slot for Network-M3, INDGW-M2 or Relay-MS cards |
Operating temperature | 0 to 40°C |
Noise level | <30 dB @ typical load |
Safety | IEC/EN 62040-1, UL1778, CSA22.2 |
EMC, Performance | IEC/EN 62040-2, IEC / EN 62040-3, FCC Class B, CISPR 32 Class B |
Approvals | CE / CB report (TUV) / cTUVus / UKCA / Ukr / Cm |
EcoDesign | RoHS, REACH, WEEE, Packaging directive, Battery directive, PEP Ecopassport |
Dimensions W x D x H / Weight | 150x345x233mm / 11kg |
