SPECIFICATIONS:
Interface
PCI-Express 4.0x4, NVMe 1.4Â Â Â Â Â
Form Factor
M.2 2280Â Â Â Â Â Â Â Â Â Â Â
Total Capacity
1TB
NAND
3D TLC NAND Flash        Â
Sequential Read speed
Up to 5,000 MB/s          Â
Sequential Write speed
Up to 4,600MB/s           Â
Dimension
80 x 22 x 2.3 mm            Â
Mean time between failure  (MTBF)
1.5 million hours            Â
Power Consumption (Active)
Average : R : 4.2W / W : 4.3WÂ Â Â Â
Power Consumption(Idle)(ASPT on)
20mWÂ
Temperature (Operating)
0°C to 70°C       Â
Temperature (Storage)
-40°C to 85°C   Â
Note
Test system configuration: configuration may vary by models, we will choose the latest platform for verification.
Performance may vary based on SSD's firmware version and system hardware & configuration. Sequential performance measurements based on CrystalDiskMark and IOmeter 1.1.0.
Speeds based on internal testing. Actual performance may vary.
1GB = 1 billion bytes. Actual useable capacity may vary.
