Grandstream GWN High-Performance AX6000 Outdoor Long-Range 802.11ax Wi-Fi 6 Access Point
The GWN7664ELR is an enterprise-grade long-range 802.11ax Wi-Fi 6 access point for medium-to-large businesses and enterprises who need to provide long-range coverage in outdoor spaces.
6 Gbps aggregate wireless throughput, 2.5 Gbps RJ45, and 2.5 Gbps SFP wireline ports Dual-band 4x4:4 MU-MIMO with OFDMA technology Self-power adaptation upon auto-detection of PoE or PoE+ Support 512 concurrent Wi-Fi client devices Up to 300-meter coverage range Advanced QoS to ensure real-time performance of low-latency applications Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device Flexibility of 8 internal antennas Embedded controller manages up to 50 local GWN APs; GDMS Networking offers unlimited AP management, & GWN Manager offers on-premise software AP management
SPECIFICATIONS:
Wi-Fi Standards | IEEE 802.11 b/g/n/ac/ax | Antennas | 8 individual internal antennas 2.4GHz, gain 5.5dBi 5GHz, gain 6.5dBi | Wi-Fi Data Rates | 5G: IEEE 802.11ax: 7.3 Mbps to 4804 Mbps IEEE 802.11ac: 6.5 Mbps to 3467 Mbps IEEE 802.11n: 6.5Mbps to 600 Mbps IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 2.4G: IEEE 802.11ax: 7.3 Mbps to 1147 Mbps IEEE 802.11n: 6.5Mbps to 600Mbps IEEE 802.11b: 1, 2, 5.5, 11 Mbps IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps *Actual throughput may vary depending on many factors including environmental conditions, distance between devices, radio interference in the operating environment and mix of devices in the network | Frequency Bands | 2.4GHz radio: 2400 - 2483.5 MHz 5GHz radio: 5150-5850 MHz *Not all frequency bands can be used in all regions. | Channel Bandwidth | 2.4G: 20 and 40 MHz (x4) 5G: 20, 40,80 and 160 MHz (x4) | System Security | WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device | MU-MIMO | 4×4:4 2.4GHz, 4×4:4 5GHz | Coverage Range | Up to 300 meters *Coverage range can vary based on environment | Maximum TX Power | 5G: 23.5dBm 2.4G: 24.5dBm *Maximum power varies by country, frequency band, and MCS rate | Receiver Sensitivity | 2.4G 802.11b: -97dBm@1Mbps, -89dBm@11Mbps; 802.11g: -93dBm @6Mbps, -75dBm@54Mbps; 802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7; 802.11ax 20MHz: -64dBm @ MCS11; 802.11ax 40MHz: -63dBm @MCS11 5G 802.11a: -93dBm @6Mbps, -75dBm @54Mbps; 802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz:-70dBm @MCS7 802.11ac 20MHz: -70dBm@MCS8; 802.11ac: HT40:- 66dBm @MCS9; 802.11ac 80MHz: -62dBm @MCS9; 802.11ax 20MHz: -64dBm @ MCS11; 802.11ax 40MHz: -61dBm @MCS11;802.11ax 80MHz: -58dBm @MCS11; 802.11ax 160MHz:-55dBm@MCS11; | SSIDs | 32 SSIDs total, 16 per radio (2.4GHz & 5GHz) | Concurrent Clients | 512 | Network Interfaces | 1x 2.5G RJ45 Port and 1x 2.5G SFP Port | Auxiliary Ports | 1x Reset Button | Mounting | Wall mount or pole mount, kits included (The mounting kits can be rotated and adjusted by 60°) | LEDs | 1 tri-color LEDs for device tracking and status indication, 1 single-color LED for SFP indication | Network Protocols | IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM | QoS | 802.11e/WMM, VLAN, TOS | Network Management | Embedded controller can manage up to 50 local GWN APs GWN.Cloud offers a free cloud management platform for unlimited GWN APs GWN Manager offers premise-based software controller for up to 3,000 GWN APs | Power and Green Energy Efficiency | PoE 802.3at; Maximum Power Consumption: 24W | Environmental | Operation:-30°Cto 60°C Storage: -30°C to 60°C Humidity: 10% to 90% Non-condensing | Physical | Unit Dimension: 260mm(L)x310mm(W)x59mm(H); Unit Weight: 1.445kg Entire Package Dimension: 469mm x 377mm x 137mm; Entire Package Weight: 3.06kg | Package Content | GWN7664ELR 802.11ax Wireless AP, Mounting Kits, Quick Installation Guide | Weatherproof Grade | IP68-level weatherproof capability | Compliance | FCC, CE, RCM, IC |
|
