INSTA360 WAVE |
|
AUDIO |
|
Number of Microphones | 8 |
Microphone Type | MEMS |
Frequency Response | 20Hz ~ 20kHz |
Voice Pickup Sampling Rate | 48kHz |
Voice Pickup Range | 5 meters (16.4 ft) |
Power Rating | 5W |
Maximum Output Sound Pressure Level | 91 dB SPL @ 0.5m/1W |
AUDIO ALGORITHM |
|
Full-duplex Audio | Yes |
Automatic Noise Suppression (ANS) | AI noise-cancelling, eliminates 300+ common noises |
Automatic Gain Control (AGC) | AI AGC |
Automatic Echo Cancellation (AEC) | AI AEC |
Dereverberation | AI-powered |
Beamforming | Omnidirectional, cardioid, super cardioid, figure-of-eight, stereo |
Audio Modes | Noise reduction, original sound |
HARDWARE |
|
Processor | AI Chip |
Storage | 4+32GB |
Battery Capacity | 9800mAh |
Input Power | 9V/2.2A, 5V/3A |
Charging Time | 5 hours |
Battery Life (talk time) | Up to 12 hours |
Screen Size | 1.82-inch customized touchscreen |
Connection Method | Dongle, Bluetooth, USB |
Device Cascade | Supports wireless linking of 3 devices *Feature available via future OTA update. |
Dimensions | Ø64.3mm (2.53in) Raised: 248mm (9.76in), Collapsed: 198mm (7.80in) |
Weight | 490g (17.3 oz) |
Operating Temperature | 32°F - 104°F (0 - 40°C) *Tested in a lab environment. |
Colors | Arctic White |
SYSTEM REQUIREMENTS |
|
Computer | Windows 10 or later, MacOS 12 or later. |
Mobile phone/Tablet | Android 10 or later, iOS 12 or later, iPad OS 12 or later. |
INSTA360 LINK 2 PRO |
|
Sensor Size | 1/1.3" |
Video Resolution | Landscape: 4K@30/25/24fps 1080p@60/50/30/25/24fps 720p@60/50/30/25/24fps 360p@30/25/24fps Portrait: 4K@30/25/24fps 1080p@60/50/30/25/24fps 720p@60/50/30/25/24fps |
Video Coding Format | H.264, MJPEG (4K and 1080p60fps Portrait mode do not support H.264) |
Exposure Compensation | ±3 EV |
ISO | Dual Native ISO 100~3200 |
Shutter Speed | 1/8000–1/30s |
White Balance | 2000–10000K |
Aperture | F/1.9 |
35mm Equivalent Focal Length | 24 mm |
Fixed FOV | 83.9º DFOV, 71.4º HFOV |
Digital Zoom | Up to 4x |
Autofocus | Supported (Focus distance: 12cm–∞) |
HDR | Supported |
Microphones | 2 |
Noise Reduction | AI Noise-Canceling |
Audio Modes | Standard, Wide, Focus, Original |
Modes | AI Tracking, Smart Whiteboard, DeskView, Virtual Background |
GIMBAL |
|
Gimbal | 2-Axis |
HARDWARE |
|
Button | 1x Touch Key |
Connectivity | USB-C Cable (USB 2.0) or USB-C to USB-A adapter |
Power Consumption | 5V/1A |
Mounting Options | Magnetic Mount with 1/4" mounting point for external tripod |
Dimensions (W x H x D) | 71.3×58.9×38mm (2.8×2.3×1.5in) |
Weight | Without Magnetic Mount: 102.5g (3.6oz) With Magnetic Mount: 167.5g (5.9oz) |
Operating Temperature | 32°F to 104°F (0°C to 40℃) *Tested in a lab environment. |
Color | Graphite Black |
SYSTEM REQUIREMENTS |
|
CPU | i5-5 generation or later (advanced features require i5-10 generation or later) |
RAM | 8GB or above (advanced features require 16GB or above) |
Link Controller | Windows: Windows 10 or later. Does not support ARM-based Windows. Mac: macOS 11.0 or later. Virtual Camera requires macOS 13.0 or later. |
Background Blur & Background Replacer | Windows: Supports all NVIDIA GPUs. AMD GPUs may experience compatibility issues; please contact the Insta360 Customer Service team before purchasing. Verified AMD GPUs include Radeon (TM), RX Vega 10, 780M, RX 560, RX 6600 and RX 6750 GRE. Mac: macOS 13.0 or later. |
Green Screen | Windows (NVIDIA GTX 1050 Ti & above): Up to 4K Windows (NVIDIA below 1050 Ti): Not supported Windows (Non-NVIDIA GPUs): Up to 4K macOS (Apple Silicon): Up to 4K macOS (Intel): Up to 1080p |
Natural Bokeh | Windows: NVIDIA GTX 1080 or later, RTX 2060 or later GPUs. Does not support AMD GPUs. Resolution support (depends on GPU capability): Desktop GPUs: Compute capability 8.6 or higher: Supports 4K and below Compute capability below 7.5: Supports 1080p and below Laptop GPUs: Compute capability 8.9 or higher: Supports 4K and below Compute capability below 8.6: Supports 1080p and below For GPU specs, visit NVIDIA’s official page. Mac: M1 chip or later. Does not support Intel chips. *Insta360 Virtual Camera is automatically installed with Link Controller. Virtual Camera supports Smart Whiteboard Mode, Natural Bokeh, Background Blur, Background Replacer, Beautify and Makeup. Virtual Camera does not support 50fps or 60fps. 4K resolution for Beautify and Makeup is currently only supported on macOS (Apple M1 or later and Intel i5 or later). |
