PERFORMANCE |
Processor | IntelĀ® Core i5-14400T, 10C (6P + 4E) / 16T, P-core 1.5 / 4.5GHz, E-core 1.1 / 3.2GHz, 20MB Intel Smart Cache |
Graphics | Integrated IntelĀ® UHD Graphics 730 |
Chipset | IntelĀ® Q670 Chipset |
Memory | 2x 8GB SODIMM DDR5-4800 |
Memory Slots | Two DDR5 SODIMM slots, dual-channel capable |
Max Memory | Up to 64GB (2x 32GB DDR5 SODIMM) |
Storage | 256GB SSD M.2 2280 PCIeĀ® 4.0x4 NVMeĀ® Opal |
Max Storage Support | Dual SSD mode: up to two drives, 2x M.2 SSD ā¢ M.2 2280 SSD up to 2TB |
RAID Preset | None |
Card Reader | No card reader |
Optical | None |
Audio Chip | High Definition (HD) Audio, RealtekĀ® ALC233VB or Conexant CX11771 codec |
Speakers | 2Wx1 |
Power Supply | 90W 89% Adapter |
DESIGN |
Keyboard | USB Traditional Keyboard, Black, English |
Mouse | USB Calliope Mouse, Black |
Expansion Slots | Three M.2 slots (one for WLAN, two for SSD) |
Case Color | Black |
Stand | None |
Adapter Cage | None |
Toolless Chassis Screw | None |
Dust Filter | None |
Mounting | None |
IO Box | No IO box |
Pen | Pen Not Supported |
Form Factor | Tiny (1L) |
Dimensions (WxDxH) | 179 x 182.9 x 36.5 mm with rubber feet (7.05 x 7.2 x 1.44 inches with rubber feet) |
Weight | Around 1.25 kg (2.76 lbs) |
CONNECTIVITY |
WLAN + Bluetooth | IntelĀ® Wi-FiĀ® 6 AX201, 802.11ax 2x2 + BT5.2 |
WWAN | Non-WWAN |
Ethernet | Integrated 100/1000M |
Front Ports | 1x USB-CĀ® (USB 5Gbps / USB 3.2 Gen 1), with 5V@0.9A charging 1x USB-A (USB 10Gbps / USB 3.2 Gen 2), with Always On and 5V@2.1A charging 1x USB-A (USB 10Gbps / USB 3.2 Gen 2) 1x headphone / microphone combo jack (3.5mm) |
Optional Front Ports (configured) | None |
Rear Ports | 1x USB-A (Hi-Speed USB / USB 2.0), with smart power-on 1x USB-A (USB 5Gbps / USB 3.2 Gen 1) 2x USB-A (USB 10Gbps / USB 3.2 Gen 2) 1x HDMIĀ® 2.1 TMDS 1x DisplayPortā¢ 1.4a (HBR2, DSC) 1x Ethernet (RJ-45) |
Optional Rear Ports (configured) | DP 1.4 |
SECURITY & PRIVACY |
Security Chip | Discrete TPM 2.0, TCG certified, FIPS 140-2 certified |
Fingerprint Reader | No fingerprint reader |
Physical Locks | KensingtonĀ® Security Slotā¢, 3 x 7 mm |
Kensington Cable Lock | None |
Chassis Intrusion Switch | Chassis Intrusion Switch |
MANAGEABILITY |
System Management | Non-vProĀ® |
CERTIFICATIONS |
Green Certifications | ENERGY STARĀ® 8.0 EPEATā¢ Silver Registered ENERGY STARĀ® 8.0 ErP Lot 3/7 RoHS compliant TCO Certified |
Mil-Spec Test | MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low Temperature, Temperature Shock, Humidity, Sand and Dust, Vibration, Shock, Solar Radiation, Contamination by Fluids, Salt Fog) |
SOFTWARE |
Operating System | WindowsĀ® 11 Pro, English |
Bundled Software | None |
ACCESSORIES |
Bundled Accessories | None |
