SPECIFICATIONS:
DISPLAY
Diagonal Size (inch)
86
Resolution
3840(H) X 2160(V)
Panel Type
VA
Panel Brightness
500 nits
Color Depth
1.07B (10bit)
Color Gamut (typ.)
72% NTSC
Color Accuracy
Delta E ≤ 1.5
Eyes Care
TÃœV Flicker FreeTÃœV Low Blue Light
Response time
6.5ms
Backlight Unit
DLED
Backlight Life (typ.)
≥ 50,000 Hours
BUILT-IN SYSTEM
Operating System
Android 13.0
Certification
Google EDLA certification
RAM
8GB
ROM
64GB
CPU
A76×4+A55×4 Octa-core
GPU
Mali-G610 MP4
NPU
6 TOPS
TOUCH SYSTEM
Touch Technology
Intelligent Touchscreen Technology(infrared recognition)
Touch Point
50 Points touch
POWER
Power Supply
100-240V~50/60Hz 4.0A
Power Consumption (standby)
≤ 0.5W
Power Consumption (typ.)
375W
AUDIO
Built-in Microphone
8-Microphone array
Microphone Pick Up Range
0-10m
Sound Channel
2.2
Speaker
2×8W+2×18W Outputs 2×12W+2×25W Maximum
CONNECTIVITY
Input
HDMI IN × 4
USB 2.0 × 1
USB 3.0 × 4
USB Type-C × 2
DP IN × 1
AUDIO IN × 1
RS232 × 1
RJ45 IN × 1
Output
HDMI OUT × 1
USB Type-C × 1
TOUCH OUT × 2
AUDIO OUT × 1
SPDIF × 1
RJ45 OUT × 1
OPS Slot
Module slot × 1
Wi-Fi Slot
Wi-Fi
Wi-Fi 6 supported
802.11ac/b/g/n/a/ax, 2.4GHz/5GHz
Bluetooth
5.2
SOFTWARE
System OS
MAXHUB EDU OS V4.0
Whiteboard Tool
MAXHUB Class
Screen Sharing
MAXHUB Connect
Device Management
MAXHUB Pivot
Google Apps
Google Play, Google Drive, Google Meet, Google map, YouTube, etc.
Other Apps
Browser, Cloud Drive, Note, Palette, WPS Office, etc.
PHYSICAL SPECIFICATION
Dimension (L×H×D)
1957×1171×86mm
Thickness of Machine and Wall Mount
116mm (WIB9060G)
Wall-hanging Screw
M8×25mm
VESA
800×600mm
Net Weight
63.55kg
Gross Weight
80.15kg
