SPECIFICATIONS:
Motherboard Size
ITX (170 x 170 mm)
CPU Socket
AM5, compatible with Ryzen 7000/8000/9000 series processors, TDP: 105-180W
Chipset
AMD® B650 high-speed chipset
Memory
Slots: 2 DIMM DDR5 slots, supporting up to
96GBDual-channel support
Dual-channel support
Frequency Support:
4800/ 5200/ 5600(OC)/ 6000(OC)/ 6400(OC)/ 6800(OC)/ 7000(OC)/ 7200(0C)/ 7600(0C)/ 7800(OC)/ 8000(OC) MHz
Display
1 x HDMI 1.4 (up to 4096 x 2160 @ 30Hz)
1 x DisplayPort (up to 4096 x 2160 @ 60Hz)
Audio
Integrated Realtek ALC897 audio chip
Network
Integrated Realtek 8125BG/D LAN chip
Onboard Realtek 8852BE WiFi 6 with Bluetooth 5.2
1 x onboard M.2 E-Key PCI-E 2230 slot for WiFi
Storage
2 x M.2 slots (supporting 2242/2280 PCle 4.0 x4/x2 SSDs)
2 x SATA 3.0 ports
USB Ports
Rear I/O: 2 x USB 3.2 Gen 1, 4 x USB 2.0
Internal Headers: 1 x USB 2.0 header (supports 2 ports),
1 x USB 3.2 Gen 1 header (supports 2 ports),
1 x USB Type-C 10G port
Additional Features
1 x 24-PIN ATX power connector
RGB Headers:
8000(OC) MHz
2 x 5V ARGB headers,
1 x 12V RGB header with MAXSUN Sync support
1 x 8-PIN ATX12V power connector (12V input)
Fan Headers:
2 system fan headers,
1 CPU fan header
1 x COM A header
1 x Rear CLR_CMOS button
1 x TPM header
