MSI Cubi N ADL S Intel N100 Barebone Mini PC (CUBI N ADL S-214BAU)
Fanless mini PC powered by Intel N100 (0.8‑3.4 GHz) with Intel HD Graphics, supports up to 16 GB DDR4‑3200 SO‑DIMM, M.2 NVMe/SATA SSD, Wi‑Fi AC 3168/9462 with BT 4.2/5, HDMI 2.1, DP 1.4, USB‑C & A, 65 W, 28‑38 dB, VESA 100×100.
Our team is ready to help! Please contact us if you have any questions about product specifications, stock availability, or compatibility.
SPECIFICATIONS:
CPU
Intel® Processor N100 (6M Cache, 0.8 GHz up to 3.4 GHz)
Chipset
Intel® SoC
Graphics
Intel HD Graphics
Cooler
Fanless
Memory
Memory not included
DDR4 3200 MHz Max 16GB SO-DIMM 1 Slots
Storage
Storage not included
1x M.2 SSD combo (NVMe PCIe Gen3 x2 / SATA
Audio
Realtek ALC256 2.1 Channel HD Audio
Communication
2x Realtek RTL8111H Intel Wireless AC 3168 + Bluetooth v4.2
Intel Wireless AC 9462 + Bluetooth v5
I/O Ports (Front)
1x Mic-in/Headphone-out combo
1x USB 3.2 Gen 2 (10G) Type C
2x USB 3.2 Gen 2 (10G) Type A
I/O Ports (Rear)
2x USB 2.0 Type A
1x (v2.1) HDMI out
1x (v1.4) DP out
Kensington Lock
Power Supply
65W
VESA
100 x 100 mm
Product Dimension (WxDxH)
124 x 124 x 53.7 (mm)
Size
0.7L Liter
Weight
0.54 (Net kg)
1.39 (Gross kg)
Noise Level
28 db Idle mode
38 db Full loading mode
Mechanical and Environmental
0° C ~ 35° C ; -20° C ~ 60° C 0% ~ 85%;0% ~ 90%
Regulatory Compliance
FCC(Class B)
CB/CE
UL(CUL)
BSMI
VCCI
RCM(C-Tick)
Product Name:
MSI Cubi N ADL S Intel N100 Barebone Mini PC (CUBI N ADL S-214BAU)
