Up to 459 mm (with <56 mm thickness fans installed at the front-right) Up to 410 mm (with 56 mm thick 420 mm AIO and fans installed at the front-right)
PSU Length
200 mm
Top Radiator & Fan Thickness
Up to 80 mm (360 mm) Up to 62 mm (420 mm)
FRONT I/O PORTS
USB 3.2 Type-A
2
USB 3.2 Gen2x2 Type-C
1
Headset Jack
1
EXPANSION SLOTS
Standard
7
Vertical
0
DRIVE BAYS
2.5"
4+2
3.5"
2
FAN SUPPORT
Front-Right
3 x 120 mm / 3 x 140 mm (1 x F420 RGB Core included)
Top
3 x 120 mm / 3 x 140 mm
Bottom
3 x 120 mm / 3 x 140 mm (1 x F420 RGB Core included)
Rear
1 x 120 mm (1 x F120 RGB (CV) included)
RADIATOR SUPPORT
Front-Right
Up to 420 mm
Top
Up to 420 mm
Bottom
Up to 360 mm
Rear
Up to 120 mm
FAN SPECS - F420 RGB CORE
Model
F420 RGB Core
Speed
2,000 ± 200 RPM
Airflow
98.61 CFM
Static Pressure
3.2 mmH2O
Noise
34.5 dBA
Fan Connector
8-pin
FAN SPECS - F120 RGB CORE (CV)
Model
F120 RGB Core (CV)
Speed
1,300 ± 130 RPM
Airflow
55.17 CFM
Static Pressure
1.27 mmH2O
Noise
26.1 dBA
Fan Connector
3-pin
CONTROL HUB SPECS
Fan Channels
3 x NZXT 8-pin (PWM only) / 1 x NZXT 8-pin (DC+PWM control) / 1 x 4-pin PWM (DC+PWM control)
RGB Channels
4 x NZXT 8-pin / 1 x NZXT RGB
Max LED Support
Each NZXT 8-pin channel supports a maximum of 96 LEDs. NZXT RGB channel supports up to 40 LEDs and up to NZXT 5 devices.
