How to Make a RJ45 Ethernet Cable Connector:1: Put the cable into the stripping port of the rj45 ethernet crimper. 2: Hold the rj45 ethernet crimping tool and rotate the cable on 360 degrees to strip the cable. (Note: Don't crimp too much tightly to avoid damaging the internal cable). 3 and 4: You will see eight colors (1-8) wires with copper core after stripping the outer cover of the cable. Then you need to line up the eight colors of the cable according to T568B standard: Orange White, Orange, Green White, Blue, Blue White, Green, Brown White, Brown. 5: After line up the eight colors of the cable, you should cut the wires neatly through the cutting port blade of the rj45 ethernet crimper. 6: Please insert the sequential cable into the end of the crystal connector. When inserting the cable into the crystal connector, hold the cable tightly to avoid the wrong sequence. 7 and 8:Insert the network cable with crystal connector into the 8P crimping port. Squeeze the handle hard and release then, pull out the crystal connector |
