PICTURE/DISPLAY |
|
Panel Size | 31.5 inch / 80 cm |
Aspect ratio | 16:9 |
LCD panel type | IPS technology |
Backlight type | W-LED system |
Pixel pitch | 0.2727x0.2727mm |
Brightness | 350 cd/m² |
Display colors | 16.7 M |
Color gamut (typical) | Adobe RGB 86.06%; DCI-P3:90.28%, sRGB: 117.22%, NTSC 108.02%.* |
Contrast ratio (typical) | 1000:1 |
SmartContrast | Mega Infinity DCR |
Response time (typical) | 4 ms (Gray to Gray)* |
Viewing angle | 178º (H) / 178º (V) @ C/R > 10 |
Picture enhancement | SmartImage game |
Maximum resolution | 2560x1440 @ 100 Hz |
Effective viewing area | 698.112(H)x392.688(V) mm |
Scanning Frequency | 30k - 150 kHz (H) / 48 - 100 Hz (V) |
sRGB | Yes |
Flicker-free | Yes |
Pixel Density | 93 PPI |
LowBlue Mode | Yes |
Display Screen Coating | Anti-glare, Haze 25%, 3H |
MPRT | 1 ms* |
EasyRead | Yes |
Adaptive sync | Yes |
HDR | HDR 10 supported |
CONNECTIVITY |
|
Signal Input | HDMI 2.0 x 2, DisplayPort 1.4 x 1 |
Sync Input | Separate Sync |
Audio (In/Out) | Audio out |
HDCP | HDCP 1.4(HDMI/DP), HDCP 2.2 (HDMI/DP) |
CONVENIENCE |
|
Plug & Play Compatibility | DDC/CI Mac OS X sRGB Windows 11 / 10 |
User convenience | Power On/Off Menu Brightness Input SmartImage Game |
OSD Languages | Brazil Portuguese Czech Dutch English Finnish French German Greek Hungarian Italian Japanese Korean Polish Portuguese Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish Ukrainian |
Other convenience | Kensington lock VESA mount (100x100mm) |
STAND |
|
Tilt | -5/20 degree |
POWER |
|
Power supply | Internal 100-240VAC, 50-60Hz |
Off mode | 0.3 W (typ.) |
On mode | 34.6 W (typ.) |
Standby mode | 0.5 W (typ.) |
Power LED indicator | Operation - White Standby mode- White (blinking) |
DIMENSIONS |
|
Packaging in mm (WxHxD) | 930 x 517 x 162 mm |
Product without stand (mm) | 715 x 420 x 62 mm |
Product with stand(max height) | 715 x 514 x 248 mm |
WEIGHT |
|
Product with packaging (kg) | 11.35 kg |
Product with stand (kg) | 7.66 kg |
Product without stand (kg) | 5.94 kg |
OPERATING CONDITIONS |
|
Altitude | Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
Temperature range (operation) | 0 to 40 °C |
MTBF | 50,000 hrs (excluding backlight) hour(s) |
Relative humidity | 20%-80 % |
Temperature range (storage) | -20 to 60 °C |
SUSTAINABILITY |
|
Environmental and energy | RoHS |
Recyclable packaging material | 100 % |
Specific Substances | PVC / BFR free housing |
COMPLIANCE AND STANDARDS |
|
Regulatory Approvals | CB CE Mark EAC EAC ROHS MEPS KC KCC CEL CCC CECP BSMI UKCA EMF FCC ICES-003 |
