PICTURE/DISPLAY |
|
Panel Size | 31.5 inch / 80 cm |
Aspect ratio | 16:9 |
LCD panel type | Fast VA |
Backlight type | W-LED system |
Pixel pitch | 0.36375x0.36375 mm |
Brightness | 300 cd/m² |
Display colors | 1.07B (10bits can be achieved through DP&HDMI@FHD 240Hz) |
Color gamut (typical) | Adobe RGB 87%; DCI-P3: 86%, sRGB: 117%, NTSC 97%* |
Contrast ratio (typical) | 3500:1 |
SmartContrast | Mega Infinity DCR |
Response time (typical) | 1 ms (Gray to Gray)* |
Viewing angle | 178º (H) / 178º (V) @ C/R > 10 |
Picture enhancement | SmartImage game |
Maximum resolution | HDMI/DP: 1920x1080@260Hz (Overclock)* |
Effective viewing area | 698.4(H)x392.85(V)mm at a 1500R curvature* |
Scanning Frequency | HDMI/DP : 30 - 390 kHz (H) / 48 - 260 Hz (V)(Overclock)* |
sRGB | Yes |
Delta E | < 2 (sRGB) |
Flicker-free | Yes |
Pixel Density | 93.24 PPI |
Display Screen Coating | Anti-Glare, 3H, Haze 25% |
SmartUniformity | 93~105% |
Low Input Lag | Yes |
EasyRead | Yes |
Adaptive sync (VRR) | Yes |
HDR | HDR 10 supported |
Smart MBR Sync | Yes |
Smart MBR | 0.3ms* |
Smart Crosshair | Yes |
Shadow Boost | Yes |
SoftBlue technology | Yes* |
CONNECTIVITY |
|
Signal Input | HDMI 2.0 x 2, DisplayPort 1.4 x 1 |
Audio (In/Out) | Audio out |
HDCP | HDCP 1.4 (HDMI / DisplayPort), HDCP 2.2 (HDMI / DisplayPort) |
CONVENIENCE |
|
Plug & Play Compatibility | DDC/CI Mac OS X sRGB Windows 11 / 10 |
User convenience | Power On/Off Menu/OK Input/Up Game Settings/Down SmartImage game/Back |
OSD Languages | Brazil Portuguese Czech Dutch English Finnish French German Greek Hungarian Italian Japanese Korean Polish Portuguese Russian Spanish Simplified Chinese Swedish Turkish Traditional Chinese Ukrainian |
Other convenience | Kensington lock VESA mount (100x100mm) LowBlue Mode |
Control software | Evnia Precision Center |
STAND |
|
Tilt | -5/20 degree |
POWER |
|
Power supply | Internal 100-240VAC, 50-60Hz |
Off mode | 0.3 W (typ.) |
On mode | 28.6 W (typ.) |
Standby mode | 0.5 W (typ.) |
Power LED indicator | Operation - White Standby mode - White (blinking) |
DIMENSIONS |
|
Packaging in mm (WxHxD) | 840 x 525 x 186 mm |
Product without stand (mm) | 709 x 426 x 96 mm |
Product with stand(max height) | 709 x 519 x 150 mm |
WEIGHT |
|
Product with packaging (kg) | 10.37 kg |
Product with stand (kg) | 6.46 kg |
Product without stand (kg) | 5.83 kg |
OPERATING CONDITIONS |
|
Altitude | Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
Temperature range (operation) | 0°C to 40°C |
MTBF | 50,000 (Excluded backlight) hour(s) |
Relative humidity | 20%-80% |
Temperature range (storage) | -20°C to 60°C |
SUSTAINABILITY |
|
Environmental and energy | RoHS |
Recyclable packaging material | 100% |
Specific Substances | Mercury free PVC / BFR free housing |
Post consumer recycled plastics | 85%* |
COMPLIANCE AND STANDARDS |
|
Regulatory Approvals | CB CE Mark UKCA EMF FCC ICES-003 BSMI MEPS PSB |
CABINET |
|
Color | Charcoal |
Finish | Textured |
