CEB (12" x 10.5"), ATX (12" x 9.6"), Micro ATX (9.6" x 9.6"), Mini-ITX (6.7" x 6.7")
Material
SGCC
Main metal thickness
1.2mm
Drive Support
External:
5.25" drive bay x 3
Internal :
8 x 3.5"
2 x 2.5” (up to 15mm)
1 x 2.5” (up to 15mm) or slim optical (12.7mm)
Cooling system
Front:
120mm x 1 (120mm x 1 fan included)
80mm x 1
Rear:
80mm x 2 (80mm x 1 fan included)
Limitation of CPU cooler
Height w/ expansion card retainer: 130mm
Height w/o expansion card retainer: 148mm
Expansion Slot
Standard profile PCI / PCIe x 7
Limitation of expansion card
Compatible up to 8.6” (220mm) in length
Compatible up to 13.3”(339mm) in length with no drives in 3.5” drive cage
Power Supply
PS2 / ATX / Mini Redundant (supports up to 200mm)
2U Redundant (RM400 V2.0 or after)
Front I/O Port
USB 3.1 Gen1 Type-A x 2
Front buttons
Power On / Off, system reset
LED Indicators
Power status x 1, HDD activity x 1, LAN activity x 2
Dimension
430mm (W) x 176mm (H) x 469mm (D)
Net Weight
10.8 kg
Notes
* The RM400 has two rows of mounting holes for sliding rails. If you wish to align RM400 in one whole U position as opposed to leaving half U height top and bottom, please secure rails to the bottom row of mounting holes. * Rail slide sold separately * Compatible with rail slide – RMS06-22
