SPECIFICATIONS:
Connector(s)
1 - Connector A
USB-C (24 pin) DisplayPort Alt Mode
1 - Connector B
Mini-DisplayPort (20 pin)
VGA (15 pin, High Density D-Sub)
DVI-I (29 pin)
HDMI (19 pin)
Environmental
Operating Temperature
0°C to 45°C (32°F to 113°F)
Storage Temperature
-10°C to 70°C (14°F to 158°F)
Humidity
Storage: 5% ~ 90 % RH (no condensation) Operating: 10% ~ 85 % RH (no condensation)
Hardware
Active or Passive Adapter
Active
AV Input
USB-C
AV Output
Mini DisplayPort - 1.2
HDMI - 1.4
DVI-I (Digital Only) - Single-Link
VGA
Chipset ID
Cypress - CYPD3120 Parade - PS8348 Parade - PS8617 Parade - PS8338 Parade - PS171 Parade - PS176
Packaging Information
Shipping (Package) Weight
4.3 oz [121 g]
Package Length
2.2 in [55 mm]
Package Width
4.1 in [10.5 cm]
Package Height
0.6 in [16 mm]
Performance
Audio Specifications
HDMI - 7.1 Channel Audio
Video Revision
HDMI 2.0
Maximum Cable Distance To Display
49.9 ft [15.2 m]
DVI - No Audio Support
DisplayPort 1.2
VGA - No Audio Support
Mini DisplayPort - 5.1 Channel Audio
Maximum Analog Resolutions
1920 x 1200 @ 60Hz
Maximum Digital Resolutions
4096 X 2160 @ 24Hz or 3840 X 2160 @ 60Hz (HDMI) 4096 X 2160 @ 60Hz (mDP)
Supported Resolutions
Maximum HDMI output: 4096 X 2160 @ 24Hz or 3840 X 2160 @ 60Hz Maximum mDP output: 4096 X 2160 @ 60Hz Maximum DVI and VGA output: 1920 x 1200 @ 60Hz Lower resolutions and refresh rates may also be supported
Wide Screen Supported
Yes
MTBF
800,703 hours
Physical Characteristics
Colour
Space Gray
Material
Aluminium
Cable Length
4.5 in [11.5 cm]
Product Length
6.9 in [17.5 cm]
Product Width
5.6 in [14.2 cm]
Product Height
1.2 in [30 mm]
Weight of Product
6.5 oz [185 g]
Note
Only one video output is supported on the video adapter at a time, if multiple connections are made, only one of the outputs will function
Maximum Cable Distance to Display refers to digital video. VGA distance capabilities are dependent upon the quality of your cabling
