CAMERA |
|
Image Sensor | 1/3 Progressive Scan CMOS sensor |
Day and Night | ICR type |
Bracket Angle Adjustment | Pan：0°to 260° |
LENS |
|
Focal Length | Fixed Lens：4mm PT Lens：6mm |
Aperture | Fixed Lens：F1.6 PT Lens：F1.6 |
FOV | Fixed Lens：Horizontal FOV: 82.3°, Vertical FOV: 44.7°, Diagonal FOV: 97.4° PT Lens：Horizontal FOV: 51.8°, Vertical FOV: 28.2°, Diagonal FOV: 60.4° |
ILLUMINATOR |
|
Supplementary Light | 6 IR Lights, 6 Spotlights |
Supplementary Light Distance | Up to 30 m/100 ft (depending on environment) |
IR Wavelength | 850nm |
Night Vision Mode | Smart Mode, Full Color Mode, Black & White Mode |
Video |
|
Video Encoding Format | Fixed Lens：H.265, H.264 PT Lens：H.265, H.264 |
Main Stream Resolution | Fixed Lens：2304 ×1296, 1920 × 1080, 1280 × 720 PT Lens：2304 ×1296, 1920 × 1080, 1280 × 720 |
Sub Stream Resolution | Fixed Lens：640 × 360 PT Lens：640 × 360 |
Frame Rate | Fixed Lens：1-25fps (2304 × 1296 1-18fps), Default 18fps PT Lens：1-25fps (2304 × 1296 1-18fps), Default 18fps |
Bit Rate | Fixed Lens：512kbps -- 4096kbps PT Lens：512kbps -- 4096kbps |
Bit Rate Control | Fixed Lens：CBR,VBR PT Lens：CBR,VBR |
AUDIO |
|
Audio Encoding Format | G.711A, G.711U, AAC |
Audio Sampling Rate | 8 kHz |
Audio Communication | Two-way Audio, Voice Input |
IMAGE |
|
Image Enhancement | DWDR, BLC, HLC, 3D DNR |
Privacy Mask | 4 Areas |
NETWORK |
|
Ethernet Port | 1 RJ45, 10Mbps/100Mbps auto-negotiation Ethernet port |
ONVIF | Support |
Protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, ARP, WebSockets |
Web Browser | Plug-in free live view: Chrome, Edge, Opera |
PAN&TILT |
|
Pan Movement Range | 0°--355° |
Tilt Movement Range | 0°--90° |
Preset | 6 |
Patrol | Panoramic Patrol, Preset Patrol |
WI-FI |
|
Antenna | Internal antenna |
Wireless Standard | IEEE 802.11 b/g/n/ax |
Transmission Rate | Up to 287Mbps |
Channel Width | 20/40 MHz |
Modulation | DSSS/OFDM/OFDMA |
Frequency Band | 2.4GHz: 2412MHz-2472MHz(CH1-CH13) |
Transmit Power | 2.4GHz: <0.1W(EIRP) |
Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
ALARM |
|
Smart Detection | Both fixed lens and PT lens are supported motion detection, human detection, vehicle detection, line crossing Detection, intrusion detection |
Smart Linkage | Sound&light Alert, Dual-lens Linkage Tracking |
DIY Audio | 3 Customized Audios |
INTERFACE |
|
Audio Input | Built-in MIC, adjustable microphone volume |
Audio Output | Built-in Speaker, 76 dBA (Alarm sound at 1 meter), adjustable sound level |
Storage | Built-in Micro SD Card Slot, Up to 512 GB |
Reset Button | Support |
LED Indicator | Dual Color(red & blue) LED Indicator |
GENERAL |
|
Material | Plastic12V DC,1A,Ø5.5mm&Ø2.1mm Power Plug |
Product Dimension | 203mm x 122mm x 162mm(8.0" × 4.8" × 6.4") |
Package Dimension | 240mm x 145mm x 193mm(9.4'' × 5.7'' × 7.6'') |
Product Weight | 527g(1.16lb) |
With Package Weight | 802g(1.77lb) |
Protection Level | IP65 |
Installation Method | Wall Mounting, Ceiling Mounting, Pole Mounting |
Certification | CE, RoHS, FCC, RCM, UKCA |
Temperature | Operating Temperature: -30°C ~ 60°C (-22°F ~ 140°F) Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F) |
Humidity | Operating Humidity: 10% ~ 95% RH (non-condensing) Storage Humidity: 3% ~ 95% RH (non-condensing) |
Package Contents | Camera Power Adapter (cord length: 3m) Installation Template Mounting Bracket Mounting Accessories Kit Waterproof Kit Quick Installation Guide |
