HARDWARE |
|
Standard&Protocol | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
CPU | 1GHz CPU |
RAM | 128MB |
Interface | 10/100/1000Mbps WAN port*1 10/100/1000Mbps LAN port*1 |
Antenna | 2 x 3dBi Internal antenna |
Button | 1 x Reset Button 1 x MESH Button |
Power | Input: AC 100-240V~50/60Hz Output:DC 12V⎓1A |
LED Indicator | SYS*1 |
Dimension | 90*90*93 mm (3.54*3.54*3.65 in.) |
WIRELESS |
|
Wireless Standard | 2.4GHz：IEEE 802.11n/b/g 5GHz：IEEE 802.11ax/ac/n/a |
Data Rate | 5GHz:1201Mbps 2.4GHz:300Mbps |
Frequency | 2.4GHz & 5GHz |
Transmission Power | CE: <20dBm(2.4GHz) <23dBm(5GHz) FCC: <30dBm(2.4GHz) <30dBm(5GHz) |
Basic Functions | OFDMA MU-MIMO Beamforming |
Wireless Security | WPA2-PSK WPA3-SAE/WPA2-PSK Wireless Encryption Disable and Enable WPS Fast Connection |
SOFTWARE |
|
Internet Connection Type | PPPoE, Dynamic IP, Static IP PPPoE(Russia), PPTP(Russia), L2TP(Russia) Unify,Maxis,Maxis-special,Celcom,Digi |
Network Protocol | IPv4&IPv6 |
Operating Mode | Router Mode,AP Mode |
Parental Control | URL Filter Time Limit |
DHCP | DHCP Server DHCP Client List DHCP Reservation |
Virtual Server | Port Forwarding DMZ Host UPnP |
Firewall | Forbid UDP Flood Attack Forbid TCP Flood Attack Forbid ICMP Flood Attack Forbid WAN Ping from Internet |
DNS | DynDNS, no-ip, oray, 88ip |
VPN | IPsec Pass Through PPTP Pass Through L2TP Pass Through PPTP VPN Server PPTP VPN Client L2TP VPN Client |
Special Features | WPA3 TR069 Tenda EasyMesh Unify 2.4 GHz & 5 GHz Smart LED on/off Amazon Alexa One-button Fault Diagnosis Broadband Account Migration Tenda App: Local and Remote ManagementSpeed Test Monthly Report |
Other Function | IPTV IPv6 Guest Network System Log Remote Web Management MAC Clone Backup & Restore configurations Support automatic access detection Firmware upgrade online |
OTHERS |
|
Temperature | 0 ~ 40 ℃ |
Humidity | 10%~90% RH non-condensing |
Certification | CE FCC RoHS |
Package Contents | Mesh3X*3 Quick Installation Guide*1 Gigabit Ethernet Cable*1 12/1A Power Adapter*3 |
