Tenda AX1500 Wi-Fi 6 Gigabit VDSL/ADSL Modem Router (V15)

Interfaces

3 *10/100/1000 RJ45 LAN Ports

1 *10/100/1000 RJ45 LAN/WAN Port

1 *RJ11 Port

1 * USB 2.0 Port

Button

WPS&Wi-Fi

RST

Power

External Power Supply

12V 1.5A

IEEE Standards

IEEE802.11b/g/n, IEEE802.11ac, IEEE802.11ax, IEEE 802.3, 802.3u, IEEE 802.1Q

VDSL2 Standards

ITU G.993.2, Up to 17a /30a/35b profile

ITU-T G.993.5 (G.vector)

ITU-T G.998.4 (G.INP)

ADSL Standards

Full-rate ANSI T1.413 Issue 2

ITU-T G.992.1(G.DMT)

ITU-T G.992.2(G.Lite)

ITU-T G.994.1 (G.hs)

ADSL2 Standards

ITU-T G.992.3 (G.dmt.bis)

ADSL2+ Standards

ITU-T G.992.5

Dimensions ( Wx D x H)

220x141.6x59mm

Antenna Type

4 * 5 dBi Antenna

WIRELESS

Wireless Standards

IEEE 802.11a/n/ac/ax 5GHz

IEEE 802.11b/g/n 2.4GHz

Frequency

20M/40M/80M

Signal Rate

300Mbps at 2.4GHz

1201Mbps at 5GHz

Wireless Functions

Enable/Disable Wireless Radio

Guest network

Access Control

WPS

MESH

Wireless Security

None, WPA, WPA2, WPA/WPA2, WPA3

Transmission Power

2.4GHz <20dBm(EIRP)

5GHz <23dBm(EIRP)

Wireless Schedule

Support

SOFTWARE

Advanced Features

PVC Configuration

DSL Settings

Routing

QoS( Based IP )

Security

MAC Filtering

IP/Port Filtering

URL Blocking

DOS

Operating Modes

VDSL/ADSL Modem Router

Wireless Router

Management

Web Based Conguration(HTTP)

Remote management

command Line Interface

SSL for TR-069

SNMP v1/2c

Web Based Firmware Upgrade

Diagnostic Tools

DHCP

DHCP Server

Client List

Address Reservation

Port Forwarding

Port Forwarding, UPnP, DMZ

Dynamic DNS

Support

VPN

PPTP

L2TP

IPsec

Protocols

Supports IPv4 and IPv6

ATM/PPP Protocols

ATM Forum UNI3.1/4.0

PPP over ATM (RFC 2364)

PPP over Ethernet (RFC2516)

IPoA (RFC1577/2225)

MER\IPoE (RFC 1483 Routed)

Bridge (RFC1483 Bridge)

PVC – Up to 8 PVCs

Guest Network

Support

CERTIFICATIONS

Certifications

CE、RoHS

ENVIRONMENT

Storage Temperature

-40℃ ~ 70℃

Operation Temperature

0℃~40℃(32℉ ~104℉)

Operating Humidity

10% ~ 90% (Non-condensing)

Storage Humidity

5% ~ 90% (Non-condensing)

PACKAGE CONTENTS

Package Contents

AX1500 Dualband Wi-Fi 6 Gigabit VDSL Modem Router*1

External Splitter*1

Power Adapter*1

RJ11 DSL Cable*2

RJ45 Ethernet Cable*1

Quick Installation Guide*1
