HARDWARE |
|
Standard&Protocol | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
CPU | 1.7GHz Quad-core CPU |
RAM | 256MB |
Interface | 3 x 10/100/1000Mbps RJ45 ports per node |
Antenna | 4 x 3dBi Internal antenna |
Button | 1 x Reset Button 1 x MESH Button |
Power | Input: AC 100-240V, 50/60Hz Output: DC 12 V ⎓ 1.5 A |
LED Indicator | 1 x Tri-color LED Indicator(Green,Yellow,Red) |
Dimension | 86x86x190mm (3.39 x3.39 x 7.48 in) |
WIRELESS |
|
Wireless Standard | 5GHz: IEEE 802.11ax/ac/n/a 2.4GHz: IEEE 802.11ax/n/b/g |
Data Rate | 2.4GHz: 574Mbps (802.11ax) 5GHz: 2402Mbps (802.11ax) |
Frequency | 2.4GHz & 5GHz |
Transmission Power | CE: <20 dBm (2.4 GHz) <23 dBm (5 GHz) FCC: <30 dBm (2.4 GHz) <30 dBm (5 GHz) |
Basic Functions | Beam Forming MU-MIMO AP Steering Band Steering OFDMA 1024-QAM |
Wireless Security | WPA3-SAE/WPA2-PSK |
SOFTWARE |
|
Internet Connection Type | PPPoE, Dynamic IP, Static IP, PPPoE(Russia), PPTP(Russia), L2TP(Russia) |
Network Protocol | IPv4&IPv6 |
Operating Mode | Router Mode,AP Mode |
Parental Control | Client Filter URL Filter Time Limit |
DHCP | DHCP Server DHCP Client List |
Virtual Server | Port Forwarding DMZ Host UPnP |
Firewall | Forbid TCP/UDP flood attack |
DNS | Support manually setting DNS server |
VPN | PPTP Server, PPTP/L2TP Client |
Special Features | Ethernet Backhaul IPv6 IPTV |
Other Function | Support App and web management Guest Network Firmware upgrade online |
OTHERS |
|
Temperature | Operating Temperature : 0℃~40℃ Storage Temperature : -40C ~70℃ |
Humidity | Operating Humidity : 10 %~90% RH non-condensing Storage Humidity : 5 %~ 90%RH non-condensing |
Certification | CE, FCC, RoHS |
Package Contents | Mesh32X*3 Quick Installation Guide*1 Gigabit Ethernet Cable*1 12/1A Power Adapter*3 |
