SPECIFICATIONS:
CAMERA |
| Image Sensor | 1/3 Progressive Scan CMOS sensor | Day and Night | ICR type | LENS |
| Focal Length | 4mm | Aperture | F2.0 | FOV | Horizontal : 83.3°, Vertical : 51.3°, Diagonal : 90.6° | ILLUMINATOR |
| Supplementary Light | 2 IR Lights | Supplementary Light Distance | Up to 10 m/32 ft (depending on environment) | IR Wavelength | 850nm | Night Vision Mode | Black & White Mode | VIDEO |
| Video Encoding Format | H.265, H.264 | Main Stream Resolution | 2880 x 1620，2560 x 1442304 × 1296, 1920 × 1080, 1280 × 720 | Sub Stream Resolution | 640 x 360 , 352 x 288 , 320x240 | Frame Rate | 1-30fps,Default 20fps | Bit Rate | 512kbps -- 4096kbps | Bit Rate Control | CBR,VBR | AUDIO |
| Audio Encoding Format | G.711A, G.711U, AAC | Audio Sampling Rate | 8 kHz | Audio Communication | Two-way Audio, One-touch Call | IMAGE |
| Image Enhancement | DWDR, BLC, HLC, 3D DNR | Privacy Mask | 4 Areas | NETWORK |
| Ethernet Port | 1 RJ45, 10Mbps/100Mbps auto-negotiation Ethernet port | ONVIF | Support | Protocols | TCP/IP, UDP, ICMP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, ARP | Client | TDSEE (mobile phone), TDSEE STUDIO (PC) | Web Browser | Chrome, Edge, Opera | PAN&TILT |
| Pan Movement Range | 0°--355° | Tilt Movement Range | -65°--90° | Preset | 6 | Patrol | Panoramic Patrol, Preset Patrol | WI-FI |
| Antenna | Internal antenna | Wireless Standard | IEEE 802.11 b/g/n/ax | Transmission Rate | Up to 287Mbps | Channel Width | 20/40 MHz | Modulation | DSSS/OFDM/OFDMA | Frequency Band | 2.4GHz: 2412MHz-2472MHz(CH1-CH13) | Transmit Power | 2.4GHz: <0.1W(EIRP) | Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK | ALARM |
| Smart Detection | Motion Detection, Tampering Detection, Human Detection, Cry Detection | Smart Linkage | Sound&light Alert, Human Tracking | DIY Audio | 3 Customized Audios | INTERFACE |
| Audio Input | Built-in MIC, adjustable microphone volume | Audio Output | Built-in Speaker, 73 dBA (Alarm sound at 1 meter), adjustable sound level | Storage | Built-in Micro SD Card Slot, Up to 512GB | Reset Button | Support | LED Indicator | Dual Color (red & blue) LED Indicator | GENERAL |
| Power | 5 V 1A, Type-C Power Plug | Material | Plastic | Smart Integration | Amazon Alexa | Product Dimension | 103mm x 88mm x 88mm (4.1'' ×3.5'' × 3.5'') | Package Dimension | 100mm x 100mm x 165mm (4.0'' ×4.0'' × 6.5'') | Product Weight | 200g (0.44lb) | With Package Weight | 370g (0.82lb) | Installation Method | Desktop, Ceiling Mounting | Certification | CE, RoHS, FCC, RCM, UKCA | Temperature | Operating Temperature: -10°C ~ 45°C (14°F ~ 113°F) Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F) | Humidity | Operating Humidity: 10% ~ 95% RH (non-condensing) Storage Humidity: 3% ~ 95% RH (non-condensing) | Package Contents | Camera Power Adapter (cord length: 1.5m) Installation Template Mounting Bracket Mounting Accessories Kit Quick Installation Guide |
|
