SPECIFICATIONS:
HARDWARE FEATURES
Standards and Protocols
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af,IEEE 802.3x, IEEE 802.1q, IEEE 802.1p, IEEE 802.3at, IEEE 802.3z
Interface
9×10/100/1000 Mbps RJ45 Ports1×1000 Mbps Combo SFP/RJ45 PortAUTO Negotiation/AUTO MDI/MDIX
Network Media
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)EIA/TIA-568 100Ω STP (maximum 100m)100BASE-TX: UTP category 5, 5e cable (maximum 100m)EIA/TIA-568 100Ω STP (maximum 100m)1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity
Fanless
Power Supply
External Power Adapter (Output: 53.5 VDC/2.43 A)
PoE Ports (RJ45)
Standard: 802.3 af/at compliantPoE Ports: Port 1- Port 8PoE Power Budget: 123 W
Dimensions ( W x D x H )
8.2 × 4.9 × 1.0 in (209 × 126 × 26 mm)
Max Power Consumption
7.66 W (220V / 50Hz with no PD connected)141.54 W (220V / 50Hz with 123 W PD connected)
Max Heat Dissipation
26.12 BTU/h (220V / 50Hz with no PD connected)482.65 BTU/h (220V / 50Hz with 123 W PD connected)
PERFORMANCE
Switching Capacity
20 Gbps
Packet Forwarding Rate
14.88 Mpps
MAC Address Table
4 K
Jumbo Frame
16 KB
SOFTWARE FEATURES
Quality of Service
Support Port-Based/802.1p/DSCP prioritySupport 4 priority queuesRate LimitStorm Control
L2 Features
IGMP Snooping V1/V2/V3Static Link AggregationPort MirroringCable DiagnosticsLoop Prevention
VLAN
Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)MTU/Port/Tag VLAN
PoE
Extend Mode**PoE Auto Recovery
Management
Web-based GUIEasy Smart Configuration Utility
Transmission Method
Store-And-Forward
OTHERS
Certification
FCC, CE, RoHS
Package Contents
TL-SG1210MPEPower AdapterInstallation GuideRubber Feet
System Requirements
Microsoft® Windows® for running Utility
Environment
Operating Temperature: 0℃~40℃ (32℉~104℉)Storage Temperature: -40℃~70℃ (-40℉~158℉)Operating Humidity: 10%~90%RH non-condensingStorage Humidity: 5%~95%RH non-condensing
