SPECIFICATIONS:
HARDWARE FEATURES
Standards and Protocols
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
Interface
16 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Network Media
10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
Fan Quantity
Fanless
Power Supply
External Power Adapter(Output: 12VDC/1.0A)
Dimensions ( W x D x H )
11.3 × 4.4 × 1.0 in. (286 × 111.7 × 25.4 mm)
Max. Power Consumption
9.19W(220V/50Hz)
Max. Heat Dissipation
31.36BTU/h
PERFORMANCE
Packet Buffer Memory
4.1Mb
Jumbo Frame
9KB
Switching Capacity
32Gbps
Packet Forwarding Rate
23.81Mpps
MAC Address Table
8K
SOFTWARE FEATURES
Quality of Service
Support Port-based/802.1p/DSCP priority
Support 4 priority queues
Rate Limit
Storm Control
L2 Features
IGMP Snooping V1/V2/V3
Static Link Aggregation
Port Mirroring
Cable Diagnostics
Loop Prevention
VLAN
Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)
MTU/Port/Tag VLAN
Transmission Method
Store-And-Forward
OTHERS
Certification
FCC, CE, RoHS
Package Content
TL-SG116E
Power Cord
Installation Guide
Rubber Feet
System Requirements
Microsoft® Windows® for running Utility
Environment
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
