Please Check Modem/Router Compatibility with your Service Providers Before Purchasing
SPECIFICATIONS:
WIRELESS |
| Standards and Protocols | Wi-Fi 4 IEEE 802.11n/b/g 2.4 GHz | WiFi Speeds | N300 2.4 GHz: 300 Mbps (802.11n) | WiFi Range | 2 Bedroom Houses 2× Fixed Antennas | WiFi Capacity | Legacy | Working Modes | Router Mode Access Point Mode Range Extender Mode Client Mode Hotspot Mode (WISP Mode) | SECURITY |
| Network Security | SPI Firewall Access Control IP & MAC Binding Application Layer Gateway | Guest Network | 1× 2.4 GHz Guest Network | WiFi Encryption | WEP WPA WPA2 WPA/WPA2-Enterprise (802.1x)* *Only Available in the Router and AP Modes. | HARDWARE |
| Processor | Single-Core CPU | Ethernet Ports | 1× 10/100 Mbps WAN/LAN Port | Power | 5 V ⎓ 1 A | Buttons | Reset Button | SOFTWARE |
| Protocols | IPv4 IPv6 | Parental Controls | URL Filtering Time Controls | WAN Types | Dynamic IP Static IP PPPoE PPTP L2TP | Quality of Service | QoS by Device | NAT Forwarding | Virtual Server Port Forwarding Port Triggering DMZ UPnP | IPTV | IGMP Proxy | DHCP | Address Reservation DHCP Client List Server | DDNS | NO-IP Comex DynDNS | Management Features | Tether App Webpage | OTHER |
| Network Services Enabled by Default | Web Server Manage and configure device through web (HTTP/HTTPS) • Port: 80/443 Protocol: TCP DHCP Server IP address assignment (DHCP) • Port: 67 Protocol: UDP App management Manage and configure device through app • Port: 20001 Protocol: TCP • Port: 20002 Protocol: UDP | System Requirements | Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access) | Certifications | FCC, CE, RoHS | Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing | TEST DATA |
| WiFi Transmission Power | CE: <20dBm(2.4GHz) FCC: <30dBm | WiFi Reception Sensitivity | 270M: -70dBm@10% PER 130M: -75dBm@10% PER 108M: -88dBm@10% PER 54M: -78dBm@10% PER 11M: -100dBm@8% PER 6M: -92dBm@10% PER 1M: -100dBm@8% PER | PHYSICAL |
| Dimensions (W×D×H) | 2.2 × 2.2 × 0.7 in (57 × 57 ×18 mm) | Package Content | Wi-Fi Router TL-WR802N Power Adapter USB Cable RJ45 Ethernet Cable Quick Installation Guide Resource CD |
|
