SPECIFICATIONS:
HARDWARE FEATURES |
| Interface | 3× 10/100/1000Mbps RJ45 LAN Ports, 1× 10/100/1000Mbps RJ45 WAN/LAN Port, 1× RJ11 Port, 1× USB 2.0 Port | Button | WPS Button, Wi-Fi On/Off Button, Reset Button | External Power Supply | 12V/1A | IEEE Standards | IEEE 802.3, IEEE 802.3u, 802.3ab | VDSL2 Standards | ITU G.993.2, Up to 17a profile (POTS) ITU-T G.993.5 (G.vector) ITU-T G.998.4 (G.INP) | ADSL Standards | Full-rate ANSI T1.413 Issue 2, ITU-T G.992.1(G.DMT), ITU-T G.992.2(G.Lite), ITU-T G.994.1 (G.hs), | ADSL2 Standards | ITU-T G.992.3 (G.DMT.bis) | ADSL2+ Standards | ITU-T G.992.5 | Dimensions ( W x D x H ) | 8.5 × 4.9 × 1.2 in (215.6 × 124.6 × 31.6 mm) | Antenna | 2× fixed Omini-Directional antennas | WIRELESS FEATURES |
| Wireless Standards | IEEE 802.11ac/n/a 5GHz, IEEE 802.11b/g/n 2.4GHz | Frequency | 2.4 GHz and 5 GHz | Signal Rate | 867Mbps at 5 GHz, 300Mbps at 2.4 GHz | Wireless Functions | Enable/Disable Wireless Radio, WMM, Wireless Statistics | Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions | Transmission Power | <20dBm (2.4 GHz), <23dBm (5 GHz) | Wireless Schedule | Support 2.4 GHz and 5 GHz Wireless Schedule | SOFTWARE FEATURES |
| Advanced Features | Parental Controls, Network Address Translation(NAT), Port Mapping (Grouping), Static Routing, DDNS, IGMP V1/V2/V3 | Security | NAT Firewall, SPI Firewall, Access Control, Service Filtering, Denial of Service (DoS), SYN Flooding, Ping of Death, IP and MAC Address Binding | Operating Modes | VDSL/ADSL Modem Router, Wireless Router, 3G/4G Router | Management Features | Web-Based Configuration (HTTP / HTTPS ), Remote management, Command Line Interface, SSL for TR-069, SNMP v1/2c, Firmware Upgrade, Diagnostic Tools, Free Online Firmware Update DHCP Server, Client, DHCP Client List, Address Reservation, DHCP Relay | Port Forwarding | Virtual Server, Port Triggering, DMZ, ALG, UPnP | Dynamic DNS | DynDns, NO-IP, TP-Link | VPN | OpenVPN, PPTP VPN, IPSec VPN | Protocols | Supports IPv4 and IPv6 | ATM/PPP Protocols | ATM Forum UNI3.1/4.0, PPP over ATM (RFC 2364), PPP over Ethernet (RFC2516), IPoA (RFC1577/2225), MER\IPoE (RFC 1483 Routed), Bridge (RFC1483 Bridge), PVC – Up to 8 PVCs | Guest Network | 2.4GHz Guest Network, 5GHz Guest Network | OTHER |
| Network Services Enabled by Default | Web Server Manage and configure device through web (HTTP/HTTPS) • Port: 80/443 Protocol: TCP DHCP Server IP address assignment (DHCP) • Port: 67 Protocol: UDP DNS • Port: 53 Protocol: TCP App management Manage and configure device through app • Port: 22 Protocol: TCP • Port: 20002 Protocol: TCP CWMP CPE WAN Management Protocol • Port: 7547 Protocol: TCP | OTHERS |
| Certification | CE, RCM, RoHS | Package Content | AC1200 Wireless MU-MIMO VDSL/ADSL Modem Router Archer VR400 External Splitter RJ11 DSL Cable RJ45 Ethernet Cable Power Adapter Quick Installation Guide | System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1, 10, macOS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser Subscription with an internet service provider (for internet access) | Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Operating Humidity: 10%~90% non-condensing |
|
