Please Check Modem/Router Compatibility with your Service Providers Before Purchasing
SPECIFICATIONS:
WIRELESS |
| Standards and Protocols | Wi-Fi 5 IEEE 802.11ac/n/a 5 GHz IEEE 802.11n/b/g 2.4 GHz | WiFi Speeds | AC750 5 GHz: 433 Mbps (802.11ac) 2.4 GHz: 300 Mbps (802.11n) | WiFi Range | 2 Bedroom Houses 2× Fixed Antennas (Internal) | WiFi Capacity | Medium Dual-Band Allocate devices to different bands for optimal performance | Working Modes | Router Mode Access Point Mode Range Extender Mode Client Mode Hotspot Mode (WISP Mode) | SECURITY |
| Network Security | SPI Firewall Access Control IP & MAC Binding Application Layer Gateway | Guest Network | 1× 5 GHz Guest Network 1× 2.4 GHz Guest Network | WiFi Encryption | WEP WPA WPA2 | HARDWARE |
| Processor | Single-Core CPU | Ethernet Ports | 1× 10/100 Mbps WAN/LAN Port | USB Support | 1× USB 2.0 Port Supported Partition Formats: NTFS, FAT32 Supported Functions: FTP Server Media Server | Buttons | Reset Button Mode Switch | Power | 5 V ⎓ 2 A | SOFTWARE |
| Protocols | IPv4 IPv6 | Parental Controls | URL Filtering Time Controls | WAN Types | Dynamic IP Static IP PPPoE PPTP L2TP | Quality of Service | QoS by Device | NAT Forwarding | Virtual Server Port Forwarding Port Triggering DMZ UPnP | IPTV | IGMP Proxy | DHCP | Address Reservation DHCP Client List Server | DDNS | NO-IP Comex DynDNS | Management Features | Tether App Webpage | OTHER |
| System Requirements | Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser Cable or DSL Modem (if needed) Subscription with an internet service provider (for internet access) | Certifications | FCC, CE, RoHS | Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Storage Temperature: -40℃~70℃ (-40℉ ~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing | TEST DATA |
| WiFi Transmission Power | CE: <20dBm(2.4GHz) <23dBm(5GHz) | WiFi Reception Sensitivity | 11a 54M: -76dBm; 11ac VHT20 MCS8: -70dBm; 11ac VHT40 MCS9: -65.5dBm; 11ac VHT80 MCS9: -61.5dBm 2.4GHz: 11g 54M: -76dBm11n; HT20 MCS7: -74dBm; 11n HT40 MCS7: -71dBm | PHYSICAL |
| Dimensions (W×D×H) | 2.91 × 2.64 × 0.87 in (74 × 67 × 22mm) | Package Content | Wi-Fi Router TL-WR902AC Power Adapter RJ45 Ethernet Cable Quick Installation Guide | Weight | 56.7 g |
|
