Please Check Modem/Router Compatibility with your Service Provider Before Purchasing
SPECIFICATIONS:
WIRELESS |
| Standards and Protocols | Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11ax/n/b/g 2.4 GHz | WiFi Speeds | AX3000 5 GHz: 2402 Mbps (802.11ax) 2.4 GHz: 574 Mbps (802.11ax) | WiFi Range | 1-3 Bedroom Houses (1-pack) TP-Link Mesh Technology Optional Ethernet backhaul work together to link Deco units to provide seamless coverage 2× Antennas (Internal) Multiple antennas form a signal-boosting array to cover more directions and large areas | WiFi Capacity | High Dual-Band Distribute devices to different bands for optimal performance MU-MIMO Simultaneously communicates with multiple MU-MIMO clients OFDMA Simultaneously communicates with multiple WiFi 6 clients 4 Streams More than enough bandwidth for connected devices | Working Modes | DSL (only on Deco X50-DSL) Router Access Point | SECURITY |
| Network Security | SPI Firewall Access Control HomeShield Security Real-Time IoT Protection Malicious Site Blocker Intrusion Prevention System DDoS Attack Prevention Home Network Scanner | Guest Network | 1× 5 GHz Guest Network 1× 2.4 GHz Guest Network | WiFi Encryption | WPA-Personal WPA2-Personal WPA3-Personal | HARDWARE FEATURES |
| VDSL2 Standards | ITU G.993.2, Up to 35b profile (POTS) ITU-T G.993.5 (G.vector) ITU-T G.998.4 (G.INP) | ADSL Standards | Full-rate ANSI T1.413 Issue 2 ITU-T G.992.1(G.DMT) ITU-T G.992.2(G.Lite) | ADSL2 Standards | ITU-T G.992.3 (G.DMT.bis) | ADSL2+ Standards | ITU-T G.992.5 | HARDWARE |
| Ethernet Ports | 4× Gigabit Ports Per Deco X50-DSL Unit Supports WAN/LAN auto-sensing | Buttons | RESET Button | Ports and Connections | 1 DSL Port Compatibility: VDSL2 / ADSL2+ / ADSL2 / ADSL | SOFTWARE |
| Protocols | IPv4 IPv6 | Service Kits | HomeShield | WAN Types | Dynamic IP Static IP PPPoE L2TP PPTP PPPoA IPoA DS-Lite | Quality of Service | HomeShield QoS QoS by Device | Cloud Service | OTA Firmware Upgrade TP-Link ID DDNS | NAT Forwarding | Port Forwarding UPnP | IPTV | IGMP Proxy IGMP Snooping Bridge Tag VLAN | DHCP | Address Reservation DHCP Client List Server | DDNS | TP-Link | Management Features | Deco App | TEST DATA |
| WiFi Transmission Power | CE: ≤20 dBm (2.4GHz) ≤23 dBm (5GHz) | PHYSICAL |
| Dimensions (W×D×H) | 4.13 × 4.13 × 6.57 in (105 × 105 × 167mm) | Package Content | 1-pack 1 Deco X50-DSL Unit 1 RJ45 Ethernet Cable 2 RJ11 DSL Cables 1 External DSL Splitter 1 Power Adapter Quick Installation Guide | OTHERS |
| Certification | CE, RCM, RoHS | Environment | Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~60°C (-40°F~140°F) Operating Humidity: 10%~90%RH Storage Humidity: 5%~90%RH |
|
