CAMERA |
|
Image Sensor | 1/2.8“ Progressive Scan CMOS Starlight Sensor |
Lens | Fixed Lens Focal Length: 2.8 mm Aperture: F1.6 Field of View: 125.5° (Diagonal), 107.8° (Horizontal), 57.8° (Vertical) PT Lens Focal Length: 6.0 mm Aperture: F1.6 Field of View: 67.1° (Diagonal), 57.8° (Horizontal), 30.1° (Vertical) |
Night Vision | 850 nm IR LED (40 ft / 12 m), Color Night Vision |
Day/Night Switch | IR-Cut Filter with Auto-Switching |
Interface & Button | 1× RESET Button 1× microSD Card Slot (Up to 512 GB) |
VIDEO & AUDIO |
|
Maximum Resolution | 2304 × 1296 px |
Frame Rate | 15 fps |
Digital Zoom | 10.8× |
Video Compression | H.264 |
Live View | Yes |
Image Enhancement | 3DNR WDR |
Audio Input & Output | Built-in Microphone and Speaker |
Audio Communication | Two-Way Audio with Noise Cancellation |
Siren Volume | 99 dB (Level measured at 4-inch/10-cm distance) |
STORAGE |
|
Local Storage | microSD Card Slot on Camera (Up to 512 GB) * MicroSD card needs to be purchased separately. Actual storage capacity depends on the size of the microSD card used. |
Cloud Storage | Tapo Care Cloud Storage Services (Subscription required) |
DETECTION AND NOTIFICATIONS |
|
AI Detection | Motion Detection Person Detection Pet Detection Vehicle Detection Line-Crossing Detection Baby Cry Detection Glass Break Detection Dog Barks Detection Cat Meows Detection Camera Tampering |
Activity Zones | Yes *Works with Motion Detection, Person Detection, Pet Detection, and Vehicle Detection |
Output Notification | System Notification System Notification with Snapshot (Tapo Care Services) |
NETWORK |
|
Network Connectivity | Connect via Wi-Fi |
Wireless Connectivity | IEEE 802.11b/g/n, 2.4 GHz Wi-Fi |
Protocol | TCP/IP, DHCP, ICMP, DNS, NTP, HTTPS, TCP, UDP |
Ethernet Port | / |
RTSP | Yes |
ONVIF | Yes |
Transmission Rate | 11b: 11 Mbps 11g: 54 Mbps 11n: 72.2 Mbps |
SECURITY |
|
Security | On-Device Machine Learning 128-bit AES Encryption with SSL/TLS PWPA/WPA2-PSK |
POWER |
|
Power Source | 5 V DC Power Adapter |
Input Voltage | 100-240 V, 50/60 Hz, 0.3A |
Output Voltage | 5.0 V, 2.0 A (Type-C Power) |
Power Cord Length | 3 m |
Typical Power Consumption | 3.0W |
Maximum Power Consumption | 9.0 W |
GENERAL |
|
Smart Integration | Google Assistant, Amazon Alexa, Samsung SmartThings |
Weather Resistance | IP65 |
Mounting Options | Tabletop Wall-Mounted Ceiling-Mounted Pole-Mounted |
Operating Temperature | -20 ºC ~ 50 ºC (-4 °F ~ 122 °F) |
Storage Temperature | -40 ºC ~ 60 ºC (-40 °F ~ 140 °F) |
Operating Humidity | 10% ~ 90% RH, Non-condensing |
Storage Humidity | 0 ~ 90% RH, Non-condensing |
Weight | 9.77 oz / 277 g |
Package Content | TC34 Camera × 1 Mounting Bracket × 1 Mounting Template Sticker × 1 Mounting Anchors × 4 Mounting Screws × 4 Power Adapter × 1 3 m USB Adapter Cable × 1 Quick Start Guide |
Dimensions( W X D X H ) | 3.07*3.02*4.20 in (78*76.83*106.83 mm) |
