HARDWARE FEATURES |
|
Interface | β’ Uplink: 1Γ 2.5G Ethernet Port β’ Downlink: 1Γ 2.5G Ethernet Port + 3Γ Gigabit Ethernet Ports (Two Gigabit ports offer flexible PoE Out, providing either dual PoE or single PoE+ output.The PoE Out feature requires 802.3bt input.) |
Physical Security Lock | Yes |
Button | Reset |
Power Supply | 802.3at/bt PoE |
PoE Out | Two Gigabit ports offer flexible PoE Out, providing either dual PoE or single PoE+ output. The PoE Out feature requires 802.3bt input. |
Max. Power Consumption | 43.35WοΌwith 25W PoE Out) |
Dimensions ( W x D x H ) | 6.8 Γ 3.6 Γ 1.6 in (172.9 Γ 91.2 Γ 41.3 mm) |
Antenna | 6Γ Internal Antennas β’ 2.4 GHz: 2Γ 5 dBi β’ 5 GHz: 2Γ 5.5 dBi β’ 6 GHz: 2Γ 5.5 dBi |
Bluetooth | V5.2 |
Mounting | Wall Mounting (Kits included) |
WIRELESS FEATURES |
|
Coverage | 1050 ftΒ² (100 mΒ²)* *Coverage value is calculated based on laboratory testing. Actual coverage is not guaranteed and will vary as a result of client limitations and environmental factors. |
Concurrent Clients | 380+** **The actual capacity depends on the wireless environment and client traffic and is generally less than the maximum number of client connections. |
Wireless Standards | IEEE 802.11 a/b/g/n/ac/ax/be |
Frequency | 2.4 GHz, 5 GHz, and 6 GHz |
Signal Rate | β’ 6 GHz: Up to 5765 Mbps β’ 5 GHz: Up to 2882 Mbps β’ 2.4 GHz: Up to 688 Mbps |
Wireless Functions | β’ MLO* β’ 4K-QAM* β’ Multi-RUs* β’ 320 MHz Bandwidth* β’ 24 SSIDs (Up to 8 SSIDs on each band) β’ Enable/Disable Wireless Radio β’ Automatic Channel Assignment β’ Transmit Power Control (Adjust Transmit Power on dBm) β’ QoS(WMM) β’ Seamless Roaming** β’ Beamforming β’ Rate Limit (Based on SSID/Client) β’ Load Balance β’ Airtime Fairness β’ Band Steering β’ Reboot Schedule β’ Wireless Schedule β’ RADIUS Accounting β’ MAC Authentication β’ Wireless Statistics β’ Static IP/Dynamic IP *Use of Wi-Fi 7 (802.11be) and features including 320 MHz Bandwidth, 4K-QAM, Multi-RUs, OFDMA and MU-MIMO requires clients to also support the corresponding features. **Omada mesh, seamless roaming, captive portal, and cloud access require the use of an Omada SDN controller. Please refer to the User Guides of Omada SDN controllers for configuration methods. |
Wireless Security | β’ Captive Portal Authentication* β’ Access Control β’ Wireless Mac Address Filtering β’ Wireless Isolation Between Clients β’ VLAN β’ Rogue AP Detection β’ WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise *Omada mesh, seamless roaming, captive portal, and cloud access require the use of an Omada SDN controller. Please refer to the User Guides of Omada SDN controllers for configuration methods. |
Transmission Power | 6-20 dBm (2.4 GHz, ERIP) 6-23 dBm (5 GHz, U-NII-1, U-NII-2A, ERIP) 6-27.5 dBm (5 GHz, U-NII-2C, ERIP) 6-23 dBm (6 GHz,ERIP) |
MANAGEMENT FEATURES |
|
Omada App | Yes |
Centralized Management | β’ Omada Hardware Controller β’ Omada Software Controller β’ Omada Cloud-Based Controller |
Cloud Access | Yes. Requiring the use of an Omad Controller. |
Email Alerts | Yes |
LED ON/OFF Control | Yes |
Management MAC Access Control | Yes |
SNMP | v1, v2c, v3 |
System Logging Local/Remote Syslog | System Log |
SSH | Yes |
Web-based Management | Yes |
L3 Management | Yes |
Multi-site Management | Yes |
Management VLAN | Yes |
Zero-Touch Provisioning | Yes. Requiring the use of Omada Cloud-Based Controller. |
OTHERS |
|
Certification | CE, RoHS |
Package Content | β’ EAP775-Wall β’ Paintable Cover β’ Installation Guide β’ Mounting Kits |
System Requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows 11, Linux |
Environment | β’ Operating Temperature: 0β40 β (32β104 β) β’ Storage Temperature: -40β70 β (-40β158 β) β’ Operating Humidity: 10β90% RH non-condensing β’ Storage Humidity: 5β90% RH non-condensing |
