VIDEO AND AUDIO |
|
IP Video Input | 8-Channel |
Incoming Bandwidth | 80 Mbps |
Outgoing Bandwidth | 60 Mbps |
HDMI Output Resolution | 1 Channel, Resolution: 3840 ×2160/30Hz, 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
VGA Output Resolution | 1 Channel, Resolution: 1920 × 1080/60Hz, 1680× 1050/60Hz, 1440 × 900/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
Video Output Mode | HDMI/VGA Simultaneous Output |
Multi-View Display | 1/4/6/8 |
DECODING |
|
Audio Compression | G.711A/G.711U/G.726 |
Video Compression | H.265+/H.265/ H.264+/H.264 |
Record Resolution | 8 MP / 5 MP / 4 MP / 3 MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
Synchronous Playback | 8-Channel* * The number of simultaneously playable channels may be fewer than eight, or none, if the total resolution exceeds 16MP. |
Capability | • 25fps: 2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP • 30fps: 4-ch @ 3MP, 2-ch @ 5MP |
RECORD MANAGEMENT |
|
Record Mode | • Manual Recording • Scheduling Recording • Motion Detection Recording |
Playback Mode | • Instant Playback • Regular Playback • Tag Playback • Event Playback |
Backup Mode | • Regular Backup • Video Clip Backup |
Playback Function | • Play • Pause • Stop • Fast Forward • Fast Backward • Play By Frame • Video Clip • Export Clip • Lock Recording • Audio On/Off |
NETWORK |
|
Protocol | UPnP (Plug and Play), NTP (Network Timing), SMTP, TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, RTSP, SSL/TLS, RTP, IPv4, ARP |
Mobile Phone Access | Android, iOS |
Web Browser | Chrome (57+), Firefox (52+), Edge (91+) |
Interoperability | ONVIF Profile S/T/G, CGI |
WIRELESS |
|
Standards and Protocols | IEEE 802.11b/g/n |
WiFi Channels | • UN: 1-13 • US: 1-11 |
Wireless Name | • SSID Configuration • Radio |
Network Switch | Yes |
Frequency | 2.4 GHz |
Radio Bandwidth | • Auto: Yes • 20M: Yes • 40M: Yes |
Wireless Rate | 300Mbps(802.11n), 2 × 2 MIMO |
Wireless Security | WPA-PSK/WPA2-PSK |
EXTERNAL INTERFACE |
|
Network Interface | • 1× RJ-45 10/100 Mbps Self-Adaptive WAN/LAN Ethernet Interface • 1× RJ-45 10/100 Mbps Self-Adaptive LAN Ethernet Interface |
USB Interface | 2× USB 2.0 |
Audio Interface | 1-ch RCA Input; 1-ch RCA Output |
Power | 1× DC Jack |
Reset Button | 1 |
Speaker | 1; Real-time Audio Output without Needing Peripherals. |
HDMI | 1 |
VGA | 1 |
HARD DISK |
|
SATA | 1 SATA Interface |
Capacity | Up to 10 TB Capacity for Each HDD** **HDD is not included. |
ALARM |
|
General Alarm | • Motion Detection • Video Tampering • Scene Change Detection • Line-Crossing Detection • Intrusion Detection • Region Entering Detection • Region Exiting Detection • Loitering Detection • Object Abandoned/Removal Detection • Vehicle Detection • Human Detection • Abnormal Sound Detection • Smart Frame Note: The alarm function requires the use of a camera. |
Anomaly Alarm | • Video Loss • Offline and IP Conflict • Disk Exception • Login Exception Note: The alarm function requires the use of a camera. |
Alarm Linkage | • Recording • White Light Alarm • Log • Audible Alarm Note: The alarm function requires the use of a camera. |
GENERAL |
|
Storage Temperature | -40–70 °C |
Storage Humidity | 10%~90% RH Non-Condensing |
Package Content | • VIGI Network Video Recorder • Power Adapter • HDD Screws • Mouse • Quick Installation Guide |
Working Temperature | • NVR: -10–55 °C • Power Adapter: 0–40 °C |
Working Humidity | 10%~90% RH Non-Condensing |
Dimensions( W X D X H ) | Excluding Antennas: 7.9 × 7.9 × 1.7 in (200.3 × 200.3 × 43 mm) |
External Power Supply | DC 12V/2A |
Net Weight | 0.5 kg |
Gross Weight | 1.0 kg |
Max. Power Consumption | • 5.7 W (Without Disk) • 16.3 W (Without Disk) |
Antenna | • Quantity: 2 • Type: 2.4GHz Welded Non-detachable Antenna • Gain: 5.3dBi • Radio Frequency Transmit Power: 16dBm • Length: 198.8 mm for Long Side and 189 mm for Short Side |
Certifications | BSMI, CE, HDMI, JRF, KC, NCC, NTRA, VCCI |
