Single-sided: 80 mm x 22 mm x 2.23 mm (3.15" x 0.87" x 0.09")
Double-sided: 80 mm x 22 mm x 3.58 mm (3.15" x 0.87" x 0.14")
Weight
8 g (0.28 oz)
INTERFACE
Bus Interface
NVMe PCIe Gen3 x4
STORAGE
Flash Type
3D NAND flash
Capacity
250GB
PERFORMANCE
Sequential Read/Write (CrystalDiskMark)
Up to 3,000/1,300 MB/s
4K Random Read/Write (IOmeter)
Up to 250,000/170,000 IOPS
Terabytes Written (TBW)
100 TBW
Mean Time Between Failures (MTBF)
2,000,000 hour(s)
Drive Writes Per Day (DWPD)
0.2 (5 yrs)
Note
• Speed may vary due to host hardware, software, usage, and storage capacity.
• The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
• Terabytes Written (TBW) expresses the endurance under the highest capacity.
• Some motherboards only provide PCIe x2 connections for the M.2 slot, creating a bottleneck on even the fastest drives.
SYSTEM REQUIREMENT
Operating System
Microsoft Windows 7 or later Linux Kernel 2.6.31 or later
Note
• Please make sure that your computer has a M.2 slot.
• Systems for use with the PCIe M.2 SSD must have an M.2 connector with only an M key. B-key connectors are not compatible. Improper insertion may lead to damage. Please click here for more information.
