SPECIFICATIONS:
Dimensions
94 × 60 × 33 mm (3.70 × 2.36 × 1.30")
Weight
156 g (5.5 oz)
Output voltage
24VDC @ 1.25A
LAN activity indicator
No
Gigabit LAN port
Yes
Remote reset capability
Reset button
Rated voltage
100-240V AC @ 50/60Hz
Input current
0.6A @ 120VAC, 0.4A @ 240VAC
Inrush current
<60A Peak @ 120VAC, <120A Peak @ 230VAC
Efficiency
83+%
Output ripple
1% Max.
Switching frequency
65 kHz
Line regulation
≤ 3%
Load regulation
≤ 5%
4-pair powering
Pins 1, 2, 4, 5 (+) and Pins 3, 6, 7, 8 (-
Storage temperature
-30 to 70°C (-22 to 158° F)
Ambient operating temperature
0 to 40° C (32 to 104° F)
Ambient operating humidity
35 to 95% noncondensing
AC connector
IEC-320 C6
Data IN / PoE
RJ45 shielded socket
Surge protection
Difference and common mode
Clamping protection
11V data, 60V power
Max. surge discharge
1500A (8/20 μs) power
Peak pulse current
36A (10/1000 μs) data
Shunt capacitance
<5 pF data
Response time
<1 ns
Certifications
CE, FCC, IC, UL
