SPECIFICATIONS:
OVERVIEW
Dimensions
212.9 x 76 x 33.5 mm (8.4 x 3 x 1.3")
Port Layout
2.5 GbE RJ45: 8 (2.5G/1G/100M/10M)
10 GbE RJ45: 1 (10G/5G/2.5G/1G/100M)
10G SFP+: 1 (10G/1G)
Form Factor
Compact Desktop, wall, DIN, magnetic
PERFORMANCE
Switching Capacity
60 Gbps
Total Non-Blocking Throughput
30 Gbps
Forwarding Rate
45 Mpps
Supported VLANs
256
MAC Address Table Size
4,000
LAYER 2 FEATURES
STP & RSTP
✓
Egress Rate Limit
Flow Control
Storm Control
Multicast & Broadcast Rate Limiting
Port Isolation
Port Mirroring
Jumbo Frames
Loop Protection
HARDWARE
Max. Power consumption
14W with PoE input 14W with AC adapter input
Power Method
(1) USB Type-C, 5V DC, 3A (1) PoE+
Power Input Method
USB Input PoE
Power Supply
AC/DC, external, 15W
Supported Voltage Range
4.8—5.2V DC/USB 44V—57V PoE
Management
Ethernet
Weight
395 g (0.87 lb)
Enclosure Material
Polycarbonate
Mount Material
Ambient Operating Temperature
-20 to 45° C (-4 to 113° F)
Ambient Operating Humidity
10 to 90% noncondensing
NDAA Compliant
Certifications
CE, FCC, IC, Anatel
SOFTWARE
Application Requirements
UniFi Network
Version 9.0.114 and later
