SPECIFICATIONS:
Mechanical
Dimensions
442.4 x 43.7 x 325 mm (17.4 x 1.7 x 12.8")
Weight
Without Mount: 5.11 kg (11.27 lb) With Mount: 5.2 kg (11.46 lb)
Enclosure Materials
SGCC Steel
Mount Material
Hardware
Total Non-Blocking Throughput
62 Gbps
Switching Capacity
124 Gbps
Forwarding Rate
92.25 Mpps
Max. Power Consumption
550W
Power Method
(1) Universal AC input: 100-240VAC, 8.5A Max., 50/60 Hz (1) USP-RPS DC input: 52VDC, 7.7A; 11.5VDC, 8.7A
Power Supply
AC/DC, Internal, 550W
Management Interface
Ethernet In-Band
Networking Interfaces
(12) 10/100/1000 Mbps RJ45 Ethernet (12) 100/1000/2500 Mbps RJ45 Ethernet
SFP+ Interfaces
(2) 1/10G SFP+
PoE Interfaces
(24) PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
Max. PoE+ Wattage per Port by PSE
34.2W
Voltage Range 802.3af Mode
44 to 57V
Voltage Range 802.3at Mode
50 to 57V
Services
SMB Layer 3 PoE Gigabit Ethernet Switch
ESD/EMP Protection
Air: ± 16 kV, Contact: ± 12 kV
Operating Temperature
-5 to 40° C (23 to 104° F)
Operating Humidity
10 - 95% Noncondensing
Certifications
CE, FCC, IC
LEDs
System
(1) Bootup Animation: Bootup in Progress Firmware Upgrade Icon: Firmware Upgrading Steady White: Factory Defaults, Awaiting Adoption Steady Blue: Device is Adopted
Ethernet
White: Link or Activity
SFP+
