OVERVIEW |
|
Dimensions | 442.4 x 285 x 44 mm (17.4 x 11.2 x 1.7") |
Port Layout | 10 GbE RJ45: 10 (All PoE+++) (10G/5G/2.5G/1G/100M) 10G SFP+: 2 (10G/1G) |
Max. PoE Output | Up to PoE+++ |
Total PoE Availability | 400W |
Redundancy | DC Power Backup |
Layer 3 | ✓ |
Form Factor | Rack mount (1U) |
Etherlighting™ | ✓ |
PERFORMANCE |
|
Switching Capacity | 240 Gbps |
Total Non-Blocking Throughput | 120 Gbps |
Forwarding Rate | 179 Mpps |
Supported VLANs | 1,000 |
MAC Address Table Size | 32,000 |
L3 Table Size | ARP Entries: 12,000 IPv4 Routes: 12,000 |
Packet Buffer Size | 2 MB |
Access Lists | IPv4: 128 MAC: 128 |
LAYER 3 FEATURES |
|
DHCP Server (Local Networks) | ✓ |
DHCP Relay | ✓ |
Inter-VLAN Routing (Local Networks) | ✓ |
Static Routing (Local Networks) | ✓ |
LAYER 2 FEATURES |
|
LACP Port Aggregation | ✓ |
STP & RSTP | ✓ |
QoS (DSCP) | ✓ |
Pro AV Profiles
(Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron) | ✓ |
Advanced IGMP Configuration
(Querier, Fast Leave, Router Port) | ✓ |
IGMP Snooping | ✓ |
802.1X Control | ✓ |
MAC-Based ACLs & Device Isolation | ✓ |
DHCP Snooping & Guarding | ✓ |
Egress Rate Limit | ✓ |
Flow Control | ✓ |
Storm Control | ✓ |
Multicast & Broadcast Rate Limiting | ✓ |
MAC Address Blocking | ✓ |
IP-Based ACLs & Network Isolation | ✓ |
MAC-Based Port Restriction | ✓ |
Port Isolation | ✓ |
Port Mirroring | ✓ |
Jumbo Frames | ✓ |
LLDP-MED | ✓ |
Voice VLAN | ✓ |
Loop Protection | ✓ |
HARDWARE |
|
PoE Ports | PoE+++: 10 |
Max. PoE Wattage per Port by PSE | PoE: 15.4W PoE+: 30W PoE++: 60W PoE+++: 90W |
Max. Power Consumption | 65W (Excluding PoE output) 520W (Including PoE output) |
Power Method | (1) Universal input, 100—240V AC, 50/60 Hz (1) USP RPS DC input |
Power Input Method | AC input |
Power Supply | AC/DC, internal, 550W |
Supported Voltage Range | 100—240V AC |
Management | Ethernet AR |
Weight | Without mounting brackets: 4.6 kg (10.14 lb) With mounting brackets: 4.7 kg (10.36 lb) |
Enclosure Material | SGCC steel |
Mount Material | SGCC steel |
Supported Rack Depth | 400~1200 mm (15.7-47.2"") |
LCM Display | 1.3" touchscreen |
ESD Protection | Air: ± 30kV, contact: ± 30kV |
Ambient Operating Temperature | -5 to 40° C (23 to 104° F) |
Ambient Operating Humidity | 10 to 90% noncondensing |
Etherlighting™ | Ethernet: ✓ SFP+: ✓ |
LEDs | RPS: ✓ System: ✓ |
NDAA Compliant | ✓ |
Certifications | CE, FCC, IC |
SOFTWARE |
|
Application Requirements | UniFi Network: Version 9.1.120 and later |
