SPECIFICATIONS:
OVERVIEW
Dimensions
442.4 x 43.7 x 480 mm
(17.4 x 1.7 x 18.9")
Port Layout
25G SFP28:
32
(25G/10G/1G)
Redundancy
DC Power Backup
Layer 3
✓
Form Factor
Rack Mount (1U)
Etherlighting™
PERFORMANCE
Switching Capacity
1.6 Tbps
Total Non-Blocking Throughput
800 Gbps
Forwarding Rate
1.2 Bpps
Supported VLANs
1,000
MAC Address Table Size
32,000
L3 Table Size
ARP Entries: 128,000
IPv4 Routes: 256,000
Packet Buffer Size
8 MB
Access Lists
IPv4: 256
MAC: 256
LAYER 3 FEATURES
DHCP Server (Local Networks)
DHCP Relay
Inter-VLAN Routing (Local Networks)
Static Routing (Local Networks)
LAYER 2 FEATURES
LACP Port Aggregation
STP & RSTP
Advanced IGMP Configuration (Querier, Fast Leave, Router Port)
IGMP Snooping
802.1X Control
MAC-Based ACLs & Device Isolation
DHCP Snooping & Guarding
Egress Rate Limit
Flow Control
Storm Control
Multicast & Broadcast Rate Limiting
MAC Address Blocking
IP-Based ACLs & Network Isolation
MAC-Based Port Restriction
Port Isolation
Port Mirroring
Jumbo Frames
LLDP-MED
Voice VLAN
Loop Protection
HARDWARE
Max. Power Consumption
200W
Power Method
(1) Universal input, 100—240V AC, 50/60 Hz
(1) USP RPS DC input
Power Input Method
AC input
Power Supply
AC/DC, internal, 200W
Supported Voltage Range
100—240V AC
Management
Ethernet
AR
Heat Dissipation (Excluding PoE Output)
457 BTU/hr
Weight
Without mounting bracket: 7.1 kg (15.7 lbs)
With mounting bracket:7.2 kg (15.9 lbs)
Enclosure Material
SGCC steel
Mount Material
Supported Rack Depth
482.6 mm (19") four-post racks
Posts depths ranging from 600 to 1,066 mm (23.6-42”)
LCM Display
1.3" touchscreen
ESD Protection
Air: ± 12kV, contact: ± 8kV
Ambient Operating Temperature
-5 to 40° C (23 to 104° F)
Ambient Operating Humidity
10 to 90% noncondensing
SFP28: ✓
LEDs
RPS: ✓
NDAA Compliant
Certifications
CE, FCC, IC
