SPECIFICATIONS:
OVERVIEW
Dimensions
122.5 x 107.1 x 28 mm
(4.8 x 4.2 x 1.1")
Port Layout
1 GbE RJ45
5 (4 PoE+; 1 PoE++)
Max. PoE Output
Up to PoE+
Total PoE Availability
46W
Form Factor
Compact desktop, wall, pole
PERFORMANCE
Switching Capacity
10 Gbps
Total Non-Blocking Throughput
5 Gbps
Forwarding Rate
7 Mpps
Supported VLANs
1,000
MAC Address Table Size
2,000
LAYER 2 FEATURES
Egress Rate Limit
✓
Flow Control
Port Isolation
Port Mirroring
Jumbo Frames
HARDWARE
PoE Ports
PoE+
PoE++
4
1
Max. PoE Wattage per Port by PSE
25W
Max. Power Consumption
5W (Excluding PoE Output)
51W (Including PoE Output)
Power Method
Power Input Method
PoE
Supported Voltage Range
50—57V PoE
Management
Ethernet
Heat Dissipation (Excluding PoE Output)
17.06 BTU/hr
Weight
230 g (8.1 oz)
Ambient Operating Temperature
46W PoE output: -40 to 55° C (-40 to 131° F)
25W PoE output: -40 to 65° C (-40 to 149° F)
ESD/EMP Protection
Air/contact: ± 16kV
Ambient Operating Humidity
5 to 95% noncondensing
Certifications
CE, FCC, IC
